High Frequency Drum-Shaped Power Ceramic Capacitor (CCG61-1, 68PF, 5KV, 3kVA)

Name: High Frequency Drum-Shaped Power Ceramic Capacitor (CCG61-1, 68PF, 5KV, 3kVA)
Brand: all-electronics-online.com
SKU: 832891305
Availability: InStock
Rating: 5 (137 reviews)

Price:	Negotiable/Piece
Min Order:	5/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	CCG61-1
Capacitance Quantity:	68PF
Directcurrent Voltage (Kv):	5kv
Rating Reactive Power:	3kVA
Temperature Quotiety Regimentation:	U(-750ppm/C)
Application:	High Voltage
Type:	Ceramic Capacitor
Package Type:	Foam Packing
Capacitance:	68PF

Product Description

1. Product Name: Drum-shaped high power ceramic capacitor CCG61-1

2. Model: CCG61-1

The capacitor is used for tank circuit,coupling,by-pass and feed circuit.

We manufacture and export the following all models.

CCG61 drum-shaped high power ceramic capacitor
Model	Nominal power capacity	Rated voltage(KV)		Reactive power	Current Maximum	Dimension(mm)			Temperature coefficient
	(PF)	DC	HF(RMS)	(KVA)	(A)	D	H	L	(PPM/ºC )
CCG61-1	15	5	4	3	1.5	21	15	90	-750
	18							89
	22							88
	27							87
	33							86
	39							85
	47							84
	56							83
	68							83
CCG61-2	39	8	6	5	2	34	19	92
	47							91
	56							90
CCG61-3	27	10	8	10	3	34	21	94
	33							93
CCG61-4	22	10	8	15	5	37	25	95

High power ceramic capacitor technical parameters:

1.Typical dissipation factor: ≤0.0008;
2.Volume resistivity: ≥10000MΩ;
3. Permissible variation of rated capacitance: K(+/-10%);
4.Temperature range: -40/+85;
5. Rated temperature: +85ºC;
6.Maximum relative humidity: 75%;
7. Test voltage: 2 times of rated voltage if the rated voltage≤15KV or 1.5 times of rated voltage if the rated voltage>15KV.

We are a skilled company and knowledgeable exporter for Electron tube, Electron valve, Ultra-high frequency electron tube, CO2 Laser power tube, Power grid tube, Ceramic vacuum tube, Electronic triode, Electronic tetrode, quadrode, pentode, Metal-ceramic transmitting tube, Broadcasting transmitter power tube, Microwave magnetron, Ceramic vacuum capacitor, Relay, Electronic components, and so on source.

Products are mainly used in high-frequency heating, plastic welding machine, Laser power supply, wood drying machine, radar scanning, RF system, Amplifier, radio transmitter, MRI and such equipments, widely applied in the textile and equipments, radio communications, medical, machining, plastics processing industries, and so on...And with over twenty years experience in export business. There is more than 480 staff, all kinds of 150 management engineers and technicians among them now. We have grown into a high efficient team to service and provide our customers with an extensive and high quality products range with competitive prices.
