Name: High Frequency Ferrite Magnetic Electronic Transformer
Brand: all-electronics-online.com
SKU: 615548614
Availability: InStock
Rating: 4.4 (149 reviews)

Price:	US $ 0.6-1.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	rm etd er ee efd pq transformer
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type1:	Current Transformer
Grewin:	High Frequency Electronic Transformer
Low Loss Magnetic Materials:	Highest Reliability of High Voltage
Ferrite Core Transformer For:	Scanner, Duplicator, Mobile Adapters
Indicative Power Capacity:	UL Insulation System for Class B (130), F (155), H
Applicable Frequency Range:	20 to 100kHz
Application 1:	PCB Circuits, Computer, TV, Monitor, Scanner
Application 2:	Duplicator, Mobile Adapters, Printer
Application 3:	Equipments and Instruments.
Core Material:	N67 Grade Material
Application:	Electronic
Phase:	Single
Coil:	Core-type Transformer
Cooling Method:	Dry-type Transformer
Winding Type:	Auto-transformer
Certification:	RoHS
Brand:	Grewin

Product Description

GREWIN's High Frequency Transformer:

Applicable frequency range: 20 to 100kHz :

Operating frequency: higher than 200kHz
High magnetic flux and low loss magnetic materials
With low leakage inductance and high efficiency .

The following transformer is for EE,ETL, PQ, EFD,ER,EPC,RM series:

Applications:

PCB circuits, computer, TV, monitor, scanner, duplicator, mobile adapters, printer and other equipments and instruments.

Features:

High frequency transformers ferrite core range depends on design parameters and the designers personal preferences.
Indicative power capacity for different core types (chart below) provides general guideline for an initial core selection
UL insulation system for Class B (130), F (155), H (180)
Can make customized lamination transformers
Power range: core type using N67 grade material
<5: RM4, P11/7, EF12.6 and U10
5 to 10: E (F) 16, RM5 and P14/8
10 to 20: RM6, E (F) 20, P18, U15 and EFD15
20 to 50: RM8, P22, RM10 ETD29, E25 and EFD20
50 to 100: ETD29, ETD34, RM12, P30 and EFD25
100 to 200: ETD34, ETD39, ETD44, P36, E30, E42 and EFD30
200 to 500: ETD44, ETD49 and E55
>500: ETD54, ETD59 and E65

3. Can make customized lamination transformers:

ETD COILFORMERS

HORIZONTAL COILFORMER DIMENSIONS (mm)
TYPE	A	B	C	D	E	F	G	H	I	J	K
ETD29	35.3	21.6	11.8	10	6.4	25	3.5	35.2	21.2	19.4	0.7
ETD34	39.6	25	13.4	11.4	-	34.6	4.5	42.8	23.4	20.9	1
ETD39	44.6	28.9	15.1	13.1	-	37	4.5	47.8	28.2	25.7	1
ETD44	49.6	31.9	17.7	15.5	-	39.9	4.5	52.2	32	29.5	1
ETD49	54.5	35.7	19.2	17	-	42.4	4.5	57.2	35.2	32.7	1
ETD54	61.5	39.15	22	19.8	-	46	4.5	61.5	39.3	36.8	1
ETD59	66.9	42.65	24.9	22.4	-	49.2	4.5	66.4	43.7	41.2	1
