High Frequency Online Battery UPS with RS232

Name: High Frequency Online Battery UPS with RS232
Brand: all-electronics-online.com
SKU: 703443012
Availability: InStock
Rating: 4.3 (68 reviews)

Price:	US $ 366-502/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	EH5000
Markets:	South America,Southeast Asia,Africa,Oceania,Mid East
Item:	Battery UPS
Wave Form:	Pure Sine Wave
Output Voltage:	Euro Standard 220V, 230V, 240V
Power Expansion:	N+X Parallel Redundancy
Wide Input Voltage:	145-275VAC 210-475VAC
Transfer Time:	0 Ms
Weight:	20-120kg
Communciation Interface:	RS232, RJ45
Output Sockets:	Universal/ IEC/NEMA/German
Frequency Range:	46-54Hz/56-60Hz
Phase:	Single Phase
Type:	On-line
Protection:	Most Power Problems
Brand:	Must/OEM

Product Description

MUST POWER LIMITED:

High Frequency Online battery ups with RS232
1. Pure Sine Wave oupt
2. Compatible with Generator well
3. Light, Fan, TV, Computer. Fax. Applications.

Model		H6KVA	H10KVA	H6KS	H10KS
Rated Power	Volt-Amps/Watts	6KVA/4.8KW	10KVA/8KW	6KVA/4.8KW	10KVA/8KW
Input	Nominal Voltage	220VAC
	Voltage Range	115 ~ 276VAC (46~54Hz)
Output	Voltage	110V/220VAC
	Frequency	Synchronized 46~54Hz(Line mode)
		50Hz ± 0.1% (Battery mode)
	Wave Form	Sine wave
	Voltage Distortion	£ 2% under linear load
	Overload Capability	105%~130% for 10 min.
	Current Crest Ratio	3:01
Battery & Charger	Type	Valve regulated, Sealed, Lead-Acid		External Battery Bank
	Nominal Voltage	192VDC
	Backup time (Full load)	17 min	15 min	Depends on the external battery capacity
Transfer Time	0 ms
LED/LCD status	Load level / Battery level, Battery, Utility Power, Inverter, Bypass, Overload, Fault
Audible Alarms	On battery mode, Battery low, Overload, Fault
Communications Interface	USB/RS-232 Serial Interface (DB-9), Intelligent Slot
Parallel Port	Availability of up to three units in parallel for power redundancy and load sharing
Physical	N.W. (Kg)	57	67.5	18	21.5
	G.W.	68	78.5	23	27.5
	Body size (w d h)	248 x 500 x 616 mm		240 x 500 x 460
	Packing size(w d h)	390680834mm		390595578mm

About products:

About sales team:

Pls contact Vena Tang:

Tel: +86 755 2910 1183

Shenzhen Must Power Limited established in 2010, with the headquarter in Hongkong, which is a professional hi-tech enterprise specialized in UPS, Power Inverter, Solar Power, VRLA Battery development, manufacturing, sales and after-service.

Our comprehensive product lines include:
Off-line UPS, line interactive UPS, On-line UPS, Solar inverter, Power inverters, Stabilizers and Solar battery.

Most of products from MUST applied with CE, FCC certificates. The main markets are Ukraine, Russia, Vietnam, Thailand, Pakistan, India, etc. Must Power Limited is one of the authorized suppliers for China Citic Bank, Ministry of Information Industry of China, Ministry of Power Industry of China, Ministry of Transportations of China.

With an excellent R & D team formed by over 30 engineers and a skilled, dedicated workforce, together 10, 000 square meter in-house manufacturing facilities in Guangdong China, Shenzhen Must Power Limited has innovated, developed and improved the products to meet the demands of customers and keep pace with changing demands of the industries. With 'close to customer' notion, we have aligned most of its resources to support our Original Equipment Manufacturer (OEM) customers, and work with our customers as power partners. Our mission is to be the best supplier of power solutions, and to accomplish this, we will continue to tailor products for market needs while maintaining high quality, integrated customer service and prompt delivery.
