| Prod Model: |
ZSF-E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Width Size: |
50-320mm ID |
| Max Temp: |
1650 Deg C. |
| Low Temp: |
-60 Deg C. |
| Capablity Of Insulation: |
16kv/mm |
| Tensile Strength: |
High |
| Working Temperature: |
560 Degree |
| Thickness: |
2-5mm |
| HS: |
70199090 |
| Company: |
Beijing Great Pack Materials Co.,Ltd |
| Application: |
Insulating Varnish |
| Type: |
Insulation Tape |
| Chemistry: |
Hybrid Insulation |
| Material: |
Fiberglass |
| Maximum Voltage: |
>100KV |
| Thermal Rating: |
650 |
| Certification: |
RoHS |
| Color: |
Red |
| Brand: |
Zeal Tape |
Product Description
Silicone rubber glass fiber insulation tape
Silicone Rubber Coated Fiberglass Fire Taps
Product Description
1, Product feature:
Suitable usded in larger diameter of the tubes or place of complex lines.
The carbon fiber high temperature insulated fire sleeving is braided with non alkali glass fiber and carbon fiber, and coated with silicon resin in high temperature.
2, Product reaction:
Thermal protection;
Insulated fireproof;
resistance to voltage;
heat insulation;
anticorrosion and flexibility.
3, Application:
Widely used in metallurgical equipment, industrial machinery, electronic appliances, electric poruducts of high temperature, such as place of heat and insulation protection.
4, Advantage feature:
1) when installation, no need to remove hose and cable, Labour and time can be saved.
2) with spriral way over lapping 30% -50% can bind, quick and convenient.
3) coil packaging, small volume light weight, installation and use of portable.
4) especially used in place of complex lines.
5, Working temperature:
Can continuous exposure to the high temperature of 560 °C, and from being damaged under the high temperature of 1650 °C, can last for 20-90 seconds.
6, Products specification:
width: 50-320mm
length: according to the site and customers requirements.
7, Free samples can be available.
Technique information:
width.(mm) |
wall thickness.(mm) |
Tolerance
(mm) |
roll length(m) |
ctn size(cm) |
No./ctn(m) |
|
50 |
2 |
±0.20 |
25 |
47*47*10 |
50 |
65 |
2 |
±0.30 |
25 |
47*47*10 |
50 |
80 |
2 |
±0.40 |
25 |
47*47*10 |
50 |
95 |
2 |
±0.40 |
25 |
47*47*10 |
50 |
110 |
3 |
±0.50 |
25 |
47*47*15 |
50 |
126 |
3 |
±0.50 |
25 |
47*47*15 |
50 |
141 |
3 |
±0.80 |
25 |
47*47*15 |
50 |
160 |
3 |
±0.80 |
25 |
52*52*20 |
50 |
175 |
3.5 |
±1.00 |
20 |
52*52*20 |
40 |
190 |
3.5 |
±1.5 |
20 |
52*52*20 |
20 |
205 |
3.5 |
±1.5 |
20 |
52*52*20 |
20 |
220 |
3.5 |
±1.5 |
20 |
52*52*20 |
20 |
240 |
4 |
±1.5 |
15 |
52*52*20 |
15 |
251 |
4 |
±2 |
15 |
52*52*20 |
15 |
270 |
4 |
±2 |
15 |
52*52*20 |
15 |
285 |
4 |
±2 |
10 |
52*52*20 |
10 |
300 |
4 |
±2 |
10 |
52*52*20 |
10 |
320 |
4 |
±2 |
10 |
52*52*20 |
10 |
FAQ
Q : Are you a factory or trading company ?
A: We are a factory , can offer best quality product and reasonable price for you.
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonable charge.
Q: What is your MOQ?
A: Normally,50Meter per color.
Q:What is your delivery time?Can we short it in 7 days or less?
A: Within 3 days for sample, 3-25 days for mass production(depend quantity).
Q: What is your payment terms?
A: T/T,Western Union paypal
Q: How can I get my order?
A: We will send you the goods by UPS, DHL, Fedex, Oversea Shipment or other forwarder, all with tracking number.
Q:How about your quality?
A: All of our products have obtained the UL and SGS certificates ,Try a small order, you will have your judgements!
