High Precision Stainless Steel Truck Scale Load Cell (B199)

Name: High Precision Stainless Steel Truck Scale Load Cell (B199)
Brand: all-electronics-online.com
SKU: 838757835
Availability: InStock
Rating: 4.6 (145 reviews)

Price:	US $ 160-180/Piece
Min Order:	4/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B199
Capacity:	20t, 30t, 40t, 50t
Out-Wire:	7 Wires
Feature:	High Accuracy
Production Process:	Strain Gauges

Product Description

Product Name: Truck Scale Load Cells Replace Tedea 120 Stainless Steel Load Cell
Model: B199
Material: Stainless Steel
Cpacity: 10t, 20t, 30t, 50t
Design
Datasheet

	Specifications	/Technique
	Capacity	10,20,30,50t
	Rated output	2±0.5%mV/V
	Zero balance	±2%F.S.
	Non-linearity	0.017% F.S.
	Hysteresis	0.017%F.S.
	Repeatability	0.017%F.S.
(30min)	Creep(300min)	0.017%F.S.
	Temp.effect on output	0.01%F.S./10ºC
	Temp.effect on zero	0.02%F.S./10ºC
	Input impedance	780±20Ω
	Output impedance	700±10Ω
	Insulation	≥5000MΩ/100VDC
	Recommended excitation	3~12V
	Maximum excitation	15V
	Compensated temp range	-10~60ºC
	Operation temp range	-30~70ºC
	Safe overload	150%F.S.
	Ultimate overload	200%F.S.
	Cable size	φ5.4×10m
	Material	Stainless Steel
	IP class	IP68

Main Features

Ideally suited to use in weighbridges
Standardized, maintenance-free, extremely compact design
Extremely robust design in hermetically sealed stainless steel housing
Special strain-gauge technology for significantly improved lightning protection
High overload range (up to 150 %)
100 % compatible with Tedea 120
Reaches stability quickly which ensures short weighing times
High EMC compatibility (10 V/m)
Additional reliability thanks to diagnostic function

This load cells could replace Tedea120 load cells directly with same design and performance. This is special for truck scales clients. Looking forward to your favorable reply.
www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
