High Quality 17vatc Cable for CATV

Name: High Quality 17vatc Cable for CATV
Brand: all-electronics-online.com
SKU: 761121165
Availability: InStock
Rating: 4.9 (144 reviews)

Price:	US $ 0.01-0.1/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	10000/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	17VATC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insulation:	Foamed PE
Braid:	Tc/CCA/Al
Application:	Coaxial Cable
Conductor Material:	Copper
Certification:	UL
Type:	Coaxial Cable

Product Description

Cavi coassiali / coaxial cables / Cables Coaxiaus / Koaxial

Coaxial and sat cables

CABLE CONSTRUCTION
Conductor	Bare Copper		1,13 +/-0,01 mm
Insulation	Foamed PE		4,90 +/-0,10 mm
1st shield	AL/PET/AL		100%
2nd shield	Tinned copper braid 16 x 4 x 0,12mm		45% coverage
3rd shield	AL/PET/AL		100%
Sheath	LSZH		6,90+/-0,10 mm
Color	White
Bending radius	≥ 8 x Diameter (mm) Installation
Storage temperature	-15ºC + 70ºC

ELECTRICAL SPECIFICATIONS @ 20 ºC
Nominal Impedance	75+/-3Ohm
Capacitance approx	52+/-2pF/m
Velocity ratio	84%

	Attenuation MHz	dB/100 m max.
	47	4,1
	230	8,6
	400	11,7
	800	16,9
	860	17,8
	1000	19,3
	1350	22,8
	1750	26,4
	2050	28,9
	2150	29,6
	2400	31,6

Hangzhou Risun Cable Co., Ltd. Specializes in manufacturing high quality Network-Cable, Telephone wire, and coaxial cable from China. Our company is located at west suburb of Hangzhou, providing convenient access to Shanghai.

Our main products are UTP/FTP Cat5e, CAT6, Telephone Cable, Coaxial Cable, Alarm cable, Patch cord etc. We implement a mature quality control system, ensure that all of our products are certified CE, which certifies that a product has met European Union health, safety, and environmental requirements, and RoHS, ISO9001. In addition, we also supply OEM service to our international clients.

We welcome your visiting to our company. And hope we can be your faithful cable supplier in China and cooperate with you in a long term. If you are interested in our products, please contact us through E-mail, fax or telephone. We will certainly pay close attention to your inquiry and reply you in time.
