| Prod Model: |
Electric Wire |
| Rated Voltage: |
300/300V, 300/500V, 450/750V |
| Standard: |
IEC, GB, JIS, BS, ASTM, DIN, UL |
| Color: |
Black, Red, Green, Grey, Yellow/Green, Required |
| Electric Wire Standard: |
IEC,ASTM,DIN.BS |
| Model: |
H07V-K;H07V-R;H07V-U |
| OEM: |
Yes |
| Manufacturer: |
Factory |
| Core: |
1, 2, 3, 4, 5, 6 |
| Popular Size: |
1.5mm,2.5mm,4mm,6mm,10mm,16mm,25mm,35mm,50mm |
| Electric Wire Price: |
According to Size and Quantity |
| Type: |
Insulated |
| Conductor Material: |
Copper |
| Certification: |
BV, SGS |
| Conductor Type: |
Solid or Stranded |
| Application: |
Building,Home,Constrction |
| Sheath Material: |
PVC, XLPE, PC |
| Insulation Material: |
PVC, XLPE, Silicone Rubber, PE |
| Range Of Application: |
Fire Resistant,Flame Retardant,Lsoh |
| Brand: |
People's Cable Group |
Product Description
Conductor:
Copper/Aluminum/Copper clad aluminum
Insulation:
PVC/PE/HDPE/XLPE
Apply voltage:
300/300V 300/500V 450/750V
Ambient Temperature:
Above 0°C
Operation temperature:
For PVC insulated wire, Operating temperature should not exceed 70°C except for Type 08.
Type 08 will allow 105°C.
Technical Parameters:
| Size of conductor | Nominal thickness of insulation mm | Mean overall diameter Upper limit mm | Approx. net weight per km kg |
| Nominal cross-sectional area mm2 | Number and diameter of wires no./mm | | | |
| 1.0 | 1/1.13 | 0.6 | 2.8 | 14 |
| 1.5 | 1/1.38 | 0.7 | 3.3 | 20 |
| 1.5 | 7/0.50 | 0.7 | 3.4 | 20 |
| 2.5 | 1/1.78 | 0.8 | 3.9 | 33 |
| 2.5 | 7/0.67 | 0.8 | 4.2 | 34 |
| 4 | 1/2.25 | 0.8 | 4.4 | 51 |
| 4 | 7/0.85 | 0.8 | 4.8 | 51 |
| 6 | 1/2.76 | 0.8 | 4.9 | 67 |
| 6 | 7/1.04 | 0.8 | 5.4 | 71 |
| 10 | 1/3.57 | 1.0 | 6.4 | 110 |
| 10 | 7/1.35 | 1.0 | 6.8 | 120 |
| 16 | 1/4.50 | 1.0 | 7.3 | 170 |
| 16 | 7/1.70 | 1.0 | 8.0 | 180 |
| 25 | 7/2.14 | 1.2 | 9.8 | 285 |
| 35 | 19/1.53 | 1.2 | 11.0 | 380 |
| 50 | 19/1.78 | 1.4 | 13.0 | 510 |
| 70 | 19/2.14 | 1.4 | 15.0 | 715 |
| 95 | 19/2.52 | 1.6 | 17.0 | 990 |
| 120 | 37/2.03 | 1.6 | 19.0 | 1230 |
| 150 | 37/2.25 | 1.8 | 21.0 | 1510 |
| 185 | 37/2.52 | 2.0 | 23.5 | 1900 |
| 240 | 61/2.25 | 2.2 | 26.5 | 2490 |
| 300 | 61/2.52 | 2.4 | 29.5 | 3050 |
| 400 | 61/2.85 | 2.6 | 33.5 | 3900 |
| 500 | 61/3.20 | 2.8 | 37.0 | 4880 |
Manufacturing Standards GB/T 12706-2008, IEC 60502-2
| Type | Name | Laying place and requirement | Long term working temperature |
227IEC01/05
BV
BLV | Copper conductor PVC insulated wires | Fixed laid indoors, conduits etc. | 70 |
| Aluminum Conductor PVC insulated wires |
227IEC07
BV-90 | Heat resistant copper conductor PVC insulated wires at 90 | Mainly be laid at the places of high temperature environment and can be laid indoors, conduits. | 70 |
| BVR | Copper conductor PVC insulated flexible wire | Be for laying permanent place where flexible required | 70 |
227IEC10
BVV | Copper conductor PVC insulated PVC sheathed round wires | Fixed laid, fit for the places with high mechanical protection and moisture place. Can be laid in the air or underground. | 70 |
| BLVV | Aluminum conductor PVC insulated PVC sheathed round wires |
| BVVB | Copper conductor PVC insulated PVC sheathed flat wires |
| BLVVB | Aluminum conductor PVC insulated sheathed flat wires |
227IEC02RV
227IEC06RV | Copper conductor PVC insulated flexible connector | Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required. | 70 |
227IECC42
RVB | Copper conductor PVC insulated flat flexible connector |
| RVS | Copper conductor PVC insulated flexible twisting connector wire |
227IEC52
RVV
227IEC53
RVV | Copper conductor PVC insulated PVC sheathed round flexible connector (light and common type) |
