| Prod Model: |
6J13 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Chemical Composition: |
Cu, Mn, Ni |
| Max Temperature: |
400 Degree |
| Color: |
Bright Finished |
| Shape: |
Wire, Ribbon, Strip, Bar |
| Carbon Content: |
Low Carbon |
| Condition: |
New |
| Type: |
Bare |
| Conductor Material: |
Copper |
| Conductor Type: |
Solid |
| Certification: |
RoHS |
| Insulation Material: |
Customized, PVC, PE, Teflon, Rubber |
| Application: |
Resistance Wire |
Product Description
Manganin Alloy Resistance Wire
1 Introduction for resistance wire
Sometimes called cupro-nickels, there exists a range of different cooper nickel alloys that possess different properties and hence are suited to a range of different applications.
2 Products and services
1. CE and ROHS cerfication;
2. Small orders are accepted;
3. Factory direct sale;
4. Timely delivery;
5. Samples are available;
3 Features of CuNi resistance alloy wire
1. Good resistance to corrosion;
2. Good malleability performance;
3. Good heating resistance;
4. Easy to be processed and lead welded;
5. Constant resistivity over a wide range of temperatures;
6. Constantan is characterized by good fatigue life and relatively high elongation capability.
4 Applications of CuNi resistance alloy wire
It is suilable for electrical resistors, potentiometers, heating wires, heating cables and underground heating mesh; Braiding and shielding in flexible coaxial cable and communication cable, a variety of audio and video cable, vehicle signal cable, network cable, data transmission cables ang so on.
5 Size
Wire: 0.018mm-10mm
Ribbon: 0.05*0.2mm-2.0*6.0mm
Strip: 0.5*5.0mm-5.0*250mm
Bar: 10-100mm
6 When you inquiry, pls specify the details
1. Material and model of wire
2. Diameter, if strip, thickness and width;
3. Quantity;
4. Special requirement if you have.
7 Photo
|
Chemical Composition and Main Property of Cu-Ni Low Resistance Alloy |
|
Properties\Grade |
CuNi1 |
CuNi2 |
CuNi6 |
CuNi8 |
CuMn3 |
CuNi10 |
|
Main Chemical Composition |
Ni |
1 |
2 |
6 |
8 |
_ |
10 |
|
Mn |
_ |
_ |
_ |
_ |
3 |
_ |
|
Cu |
Bal |
Bal |
Bal |
Bal |
Bal |
Bal |
|
Max Continuous Service Temperature(ºC) |
200 |
200 |
200 |
250 |
200 |
250 |
|
Resisivity at 20ºC (Ω*mm²/m) |
0.03 |
0.05 |
0.1 |
0.12 |
0.12 |
0.15 |
|
Density(g/cm³) |
8.9 |
8.9 |
8.9 |
8.9 |
8.8 |
8.9 |
|
Thermal Conductivity(α×10-6ºC) |
<100 |
<120 |
<60 |
<57 |
<38 |
<50 |
|
Tensile Strength(Mpa) |
≥210 |
≥220 |
≥250 |
≥270 |
≥290 |
≥290 |
|
EMF vs Cu(μVºC)(0~1000ºC) |
-8 |
-12 |
-12 |
-22 |
_ |
-25 |
|
Approximate Melting Point(ºC) |
1085 |
1090 |
1095 |
1097 |
1050 |
1100 |
|
Micrographic Structure |
austenite |
austenite |
austenite |
austenite |
austenite |
austenite |
|
Magnetic Property |
non |
non |
non |
non |
non |
non |
|
|
|
Properties\Grade |
CuNi14 |
CuNi19 |
CuNi23 |
CuNi30 |
CuNi34 |
CuNi44 |
|
Main Chemical Composition |
Ni |
14 |
19 |
23 |
30 |
34 |
44 |
|
Mn |
0.3 |
0.5 |
0.5 |
1 |
1 |
1 |
|
Cu |
Bal |
Bal |
Bal |
Bal |
Bal |
Bal |
|
Max Continuous Service TemperatureºC) |
300 |
300 |
300 |
350 |
350 |
400 |
|
Resisivity at 20ºC (Ω*mm²/m) |
0.2 |
0.25 |
0.3 |
0.35 |
0.4 |
0.49 |
|
Density(g/cm³) |
8.9 |
8.9 |
8.9 |
8.9 |
8.9 |
8.9 |
|
Thermal Conductivity(α×10-6ºC) |
<30 |
<25 |
<16 |
<10 |
<0 |
<-6 |
|
Tensile Strength(Mpa) |
≥310 |
≥340 |
≥350 |
≥400 |
≥400 |
≥420 |
|
EMF vs Cu(μVºC)(0~1000ºC) |
-28 |
-32 |
-34 |
-37 |
-39 |
-43 |
|
Approximate Melting Point(ºC) |
1115 |
1135 |
1150 |
1170 |
1180 |
1280 |
|
Micrographic Structure |
austenite |
austenite |
austenite |
austenite |
austenite |
austenite |
|
Magnetic Property |
non |
non |
non |
non |
non |
non |
