High Quality Insulation Fish Paper

Name: High Quality Insulation Fish Paper
Brand: all-electronics-online.com
SKU: 805310135
Availability: InStock
Rating: 5 (102 reviews)

Price:	US $ 1.3-1.5Kg
Min Order:	1000Kg
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	o
Colour:	Main Green
Electric&Nbsp;Breakdown&Nbsp;Voltage:	>=3.5kv
Bond&Nbsp;Strength&Nbsp;:	No Delamination&Blister;
Application:	Electrical Base, Shell
Type:	Insulation Paper
Chemistry:	Organic Insulation
Material:	Paper
Thermal Rating:	E 120
Maximum Voltage:	<10KV
Color:	Cyan
Brand:	Toyo

Product Description

Packaging & Delivery
Packaging Details: Standard Package: Reel packaging or Flat packaging; We can also pack it according to the customers' requirements.
Delivery Detail:3-7 days
Specifications

thickness is around 0.1~0.3mm

Product Description

Fish paper is with good mechanical strength, high electrical strength, product surface level off is smooth, rich toughness, widely used in motors, electrical appliances, instruments and other equipment for insulation materials, used to make 6250 polyester thin film composite foil at the same time.

Such as household ceiling fan fan blade and fan head with screw fastening in the interval between a layer of green shell paper.

Lathe spindle pressure between ring and gear box has fish paper clip.

Technical Data Sheet

Properties	Units	Values
Nominal thickness	mm	0.15 0.17 0.20 0.30
Thicknessallowed tolerance	mm	±0.02 ±0.02 ±0.03 ±0.03
Nominal grammage	g/m2	155 180 210 300
Film nominal thickness	um	30 30 30 30
Tensile strength(MD)	N/10mm	≥100 ≥110 ≥120 ≥200
Tensile strength(XD)	N/10mm	≥70 ≥75 ≥80 ≥105
Elongation(MD)	%	≥2 ≥2 ≥2 ≥2
Elongation(XD)	%	≥8 ≥8 ≥8 ≥8
Electric breakdown voltage	KV	≥3.5 ≥3.5 ≥3.5 ≥5

Packaging & Shipping

Normally the out - packaging for the goods is wooden pallet or wooden case, we can deliver it by air or by ship.
Airport: Beijing, Tianjin, Qingdao, Nanjing, Shanghai, Guangzhou, Shenzhen
Sea Port: Tianjin,Qingdao, Shanghai, Ningbo, Guangzhou
Packing Type Photo is as the following:

We are major in insulation material of various classes, from B to F, and from F to H, TOYO'S products are widely used in Motors, Generators, Welders, Electrical Heaters, and etc. And provide assurances for their long time, stability work.

The test results of from SGS Shanghai branch indicate that the TOYO's products are in conformity with EU RoHS Directive 2002/95/EC and subsequent revision directives. And our product conforms to REACH regulation's requirements (the newest version) of European Union after tested, and also passed UL certification of American and Canada.

" TOYO" Team was composed of many senior electrical engineers, and insist on response to every client's enquiry 100%. Maintaining good cooperative relationship with main manufacturers in domestic for long term, and this provides " TOYO" With stable product quality; Reasonable prices; Timely supply.

We started to do the foreign trade since 2014, because of the good faith, now we have had so many customer from home and abroad. We are also planning to making the investment to enhance the relationship with our key suppliers, and meet our customer's requirements.

Welcome you to contact us and discuss business at any time.
