High Quality Quartz Tube for Quartz Infrared Heater Element

Name: High Quality Quartz Tube for Quartz Infrared Heater Element
Brand: all-electronics-online.com
SKU: 818720605
Availability: InStock
Rating: 4.8 (110 reviews)

Price:	Negotiablepcs
Min Order:	50pcs
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	Quartz Tube
Function:	Heating

Product Description

Product Information:

Product Description
1. Silicon Dioxide >99.95%, Excellent visual and chemical performance, high thermo-stability, anticorrosive, transmittance of visible light >90%.
2. Size: OD: 3-300mm, Thickness: 0.5-10mm, Length: 10-3000mm
3. Material : Quartz glass
4. Purity: More than 99.99%

Dimensional Tolerance

Range of OD	OD	WT	Siding	Ellipsticity	Camber/1220mm
≤5mm	±2.0%	±10%	12%	2.0%	2.5mm
6-15mm	±1.25%	±8%	10%	1.5%	2.5mm
15-20mm	±1.25%	±10%	15%	1.5%	2.5mm
20-25mm	±1.25%	±10%	15%	1.5%	3.0mm
25-30mm	±1.35%	±12%	15%	1.5%	3.0mm
30-80mm	±1.5%	±14%	15%	2.0%	3.0mm
80-300mm	±1.5%	±14%	15%	2.0%	3.0mm

Chemical Composition unit: ppm

Cr	Ge	Fe	Mg	Ti	Ca	AI	Na	Li	K
0.1	0.4	1.5	0.4	0.1	0.8	16	2.3	1.5	2.0

Lights transmittance

nm	≤220	255	280	315	350	380	590	780
%	89	91	93	93	93	93	93.2	93.4

Application:
Widely used in the filed of semiconductor, metallurgy, chemical industry, electric light source, medical equipment, scientific instruments and so on.

Packing and Delivery
1. Packing details: Standard export package
2. Delivery time: within 15 days
3. Delivery ways: by air, sea or express

Since 1985 years, Superb Heater Technology has been focused on the production of high quality quartz tube for quartz infrared heater element, which is well-known as one of the leading manufacturers and suppliers of high quality quartz tube for quartz infrared heater element. In the past years, we owned strong reputation for the high quality, reliable performance and strong durability of our products. Should you have interested, please feel free to contact us.

Shenzhen superb heater technology Co., Ltd, Founded in 1985, Start is a state run Magnesium Oxide factory, After privatization reform To become a professional to provide all kinds of electric heating products of the comprehensive private joint-stock companies, After years of development company now grown to have include: ChaoHu heating material fitting, JiuDing machinery and spare parts, LiLin cartridge heaters, chaohu band coiling heaters, JXC Industrial heaters five plants, more than 200 employees, assets of more than $ 5 million, Products include various types of industrial heater, cartridge heater, hot runner, thermocouples, band heater and a variety of heater materials and heater equipment to meet customers one-stop shopping for all kinds of heating element, heating materials and heating equipment needs.

Over the years we are committed to technology and product quality improvement, many products similar products meet international quality, in China in the lead, swaged-in leads cartridge heater and diameter less 4mm cartridge heater as China's first single, cost-effective products to give our customers highly recognized, it has been to establish and maintain long-term cooperative relations with more than 700 customers in over 40 countries.

We will insist on our stable style to establish good image in both customers and our partners. We have been insisting on the "REDUCING THE COST AND GIVING ADVANGTAGE TO CUSTOMERS " To provide customers with better products and services, and grow with customers

After long-term accumulation, we have set up agents and partners in India, Dubai, USA, Russia, Brazil, Argentina, Thailand, Korea and other countries to provide convenient and quick service
