High Quality Spool Insulator (53-1, 53-2, 53-3)

Name: High Quality Spool Insulator (53-1, 53-2, 53-3)
Brand: all-electronics-online.com
SKU: 662936182
Availability: InStock
Rating: 4.5 (121 reviews)

Price:	US $ 0.2/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	53-1, 53-2, 53-3
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Chemistry:	Hybrid Insulation
Thermal Rating:	250 250
Failing Load:	27kn
Model:	Can Be Made to Order
Application:	Insulators
Material:	Porcelain
Structure:	Shackle Insulator
Type:	Solid
Size Of Bearing Capacity:	9kn-27kn
Color:	Brown
Brand:	Powlik

Product Description

Spool Insulator (53-1, 53-2, 53-3)

Fug		1	1	2	3	2	2	4
Cat.No.		10506	10507	10501	10502	10503	10504	10505
Type		1617	1618	53-1	53-2	53-3	53-4	53-5
Transverse Strength KN		9	13	9	13	18	20	27
Low Frequency Dry FlashoverKV		20	20	20	25	25	25	35
Low Frequency Dry Flashover Voltage		9	10	10	15	15	15	25
Low Frequency Dry Flashover Voltage		1	1	8	12	12	12	18
Dimensions MM	H	65	75	54	76	80	76	105
	D	76	89	57	79	76	105	102
	d	46	55	44	44	44	73	73
	d1	17.6	17	17.5	17.5	17.5	17.5	17.5
	R	9	12.5	11	17.5	11	16	11
Net Weight,Each,Approx,KG		0.4	0.6	0.2	0.5	0.6	1.05	1.2

Material: Porcelain
Standard:ANSI,IEC
It can be ordered according to customer's different requirements
