High Quality Varnish Silk Cloth Insulation Materials

Name: High Quality Varnish Silk Cloth Insulation Materials
Brand: all-electronics-online.com
SKU: 743406005
Availability: InStock
Rating: 4.6 (139 reviews)

Price:	US $ 10-32kg
Trade Terms:	FOB,CFR,CIF
Min Order:	1kg
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MJ-2310
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Width:	More Than 1000mm
Thickness:	0.15±0.02 Mm
Breakdown Voltage (at Room Temperature):	7
Formation Methods:	High Temperature and High Pressure
Appliction:	Motor & Generator
Delivery:	7-10 Working Days
Customizable:	Yes
MOQ:	1 Piece
Application:	Generator
Chemistry:	Hybrid Insulation
Thermal Rating:	E 120
Maximum Voltage:	>100KV
Type:	Mica Tape
Material:	Alkali Free Silk Cloth with Alkyd Resin
Brand:	Mj

Product Description

Feature: Insulation polyimide film
Excellent dielectrical property
Good mechanical property
Excellent heat resistance property
Good moisture resistance
Self-adhesive

Application:
Vacuum varnished cloth
Used for the grade H heavy-duty generator
Electric motor
Electric equipment's binding up
Or as liner insulation
Technical Parameters:

Basic information
Product name	2310 Varnish Silk Cloth
Brand	MJ-2310 glass varnished fabric
Material	Alkali free silk cloth with alkyd resin
Grade	E
Feature
Good dielectrical and mechanical property Good heat resistance Less thickness tolerance
Application
can be used as liner insulation and coil insulation for the binding and insulating materials for the electric motor,appliance.etc
Technical Performance
Shrinkage (After treated at temperature of 105±2°C for 6h)	≤ 1%
Normal thickness (mm)	0.08 0.1 0.12 0.15
Tolerance (mm)	±0.01 ±0.01 ±0.015 ±0.015
Tensile strength (N/10mm) warp-wise across warp 45°
	≥ 22 ≥ 24 ≥ 25 ≥ 30
	≥ 15 ≥ 17 ≥ 18 ≥ 22
	≥ 15 ≥ 17 ≥ 17 ≥ 17
Breakdown voltage (KV) Under23±2 °C After bending Under23±2 °C Under105±2OC Sweat 24 hours after Shrinkage 6% Under 450
	4.8 5.8 7.2 8.7
	3.0 4.4 6.3 6.9
	3.0 4.3 5.2 5.8
	2.3 3.5 4.1 4.7
	2.7 4.1 5.0 6.1
The quality warranty period	Six months (under25 °C )

Our company is in Xi' An high tech Development Zone, mainly producing magnetic/electrical insulation laminates, slot wedges, thermal expansion materials, insulation varnish, impregnated cloth, insulation tube/sleeve/rod and etc. Our products are widely used in the fields of wind & thermal power, aviation, railway, military power transmission, motors and transformers and etc.

We have experts in R&D group which ensure the continuity and stability of the product quality and cost. The issued testing results apply to domestic and internaltional standards.

Our company covers 5000 square meters with 4 production departments: Magnetic board, Insulating materials, High voltage electrical appliance, CNC and slot wedge processing. WIth more than 50 sets of reactor, gluing machine, large-scale equipment, hot press, high vacuum impregnation and testing equipments, our annual production capacity can totally reach 800 tons.

We are founded in 2006. By 2007-2008, we passed 9001-2000 certification, Xi' An city Science and Technology Bureau identified us as "the city of Xi' An high-tech enterprises".

The spirit of our company is: "Good Reputation, Best Products, Wonderful Services
