High Short-Circuit Breaking Capacity Miniature Circuit Breaker

Name: High Short-Circuit Breaking Capacity Miniature Circuit Breaker
Brand: all-electronics-online.com
SKU: 694034555
Availability: InStock
Rating: 4.9 (61 reviews)

Price:	NegotiablePoles
Trade Terms:	FOB,CIF
Min Order:	1000Poles
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	TGA7
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current(a):	1,2,3,4,6,10,16,20,25,32,40,50,63
Rated Frequency:	50/60Hz
Rated Voltage:	230/400V AC
Rated Short-Circuit Making Capaity:	1000A
Breaking Capacity:	Low Voltage Circuit Breakers
Arc-extinguishing Medium:	Air
Installation:	Fixed
Certification:	CE
Function:	Overload, Short-Circuit Protection

Product Description

Construction And Feature
Capable of switch electric circuit with load
Capable of quickly releasing stored energy operation
Adaptable to padlock device
Contact position indication
High short-circuit current withstand capacity
Highlighted of high making and breaking capacity
Used as main switch for household and similar installation

Pole No.	1,2,3,4
Rated current(A)	1,2,3,4,6,10,16,20,25,32,40,50,63
Rated frequency	50/60hz
Rated voltage	230/400V AC
Rated withstand current	1000A within 1sec
Electro-mechanical endurance	1000 cycles
Rated short-circuit making capaity	1000A
Connection capacity	Rigid conductor 25mm2
Connection terminal	Screw terminal Pillar terrminal with clamp
Installation	Panel mounting

Long Road Electric Co. Ltd founded in 2010, is located in the largest manufacturing base of low-voltage electric equipment of Wenzhou China, which is called "the Electric Device Metropolis of China". Long Road Electric specialized in the SMC, DMC and PLASTIC materials energy meter boxes Manufacturing, International trade and service.

Long Road Electric Co, Ltd regards quality of products as life, Longroad Electric Co., Ltd has been granted ISO9001 management system certifications. The comprehensive product line has more than 100 models which have been approved by TUV, CE, CB, SGS, RoHS, SASO. The products sells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa, Nigeria etc...More than 70 countries and regions.

Long Road Electric Co. Ltd is always striving hard to provide the best services and competitve pricing to all customers.
