High Technical Pushbutton Switch Ad22-22ds/G

Name: High Technical Pushbutton Switch Ad22-22ds/G
Brand: all-electronics-online.com
SKU: 684148082
Availability: InStock
Rating: 5 (84 reviews)

Price:	US $ 0.17-0.19/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	300/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	AD22-22DS/G
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Conventional Heating Current:	10A
Rated Insulation Voltage:	AC600V(50Hz-60Hz)
Operational Temperation:	-25~70centigrade
Operational Humidity:	≤ 85%
Power-Frequency Withstand Voltage:	2500V AC, 1min
Color:	Black, Green, Red, Yellow, Blue
Certificates:	CE, CCC, RoHS
Type:	Normal Open
Usage:	Check Button
Kind:	Single-pole on-off Switch
Brand:	Lovadon

Product Description

Type: ADD22-22DS/G
Description: (Push button switch)
1. Protected LED indicator
2. Standard handle
3. Voltage:
6V AC/DC
12V AC/DC
24V AC/DC
36V AC/DC
48V AC/DC
110V AC/DC
127V AC/DC
220V AC/DC
220V* AC/DC
380V* AC/DC
Application and main technical parameters of this series:
1) Conventional heating current: 10A
2) Rated insulation Voltage: AC600V(50Hz-60Hz)
3) Operational temperation: -25~70Centigrade
4)Operational humidity: ≤ 85%
5) power-frequency withstand voltage: 2500V AC, 1min
6) contact resistance: ≤ 50mΩ
7) Mechanical durability: 1000000(pushbutton). 500000(selector switch/key switch)
8) Electrical durability: 500000(pushbutton). 250000(selector switch/key switch)
9)Color: Black, green, red, yellow, blue
10)Contact type: N/O, N/C, N/O+N/C, N/O+N/O
11)Certificates: CE, CCC, RoHS
12)Packing: Standard export packing
Our switch is safe and reliable, specially designed for Industrial equipments, with good quality and very competitive prices. This switches also with different kinds for different functions, like spring return type, self-locked type, with lamp type, mushroom head type, selector type, with key type and emergency stop type, etc.

Conventional heating current	Rated insulation Voltage	Operational temperation	Operational humidity	power-frequency withstand voltage	contact resistance	Color	Certificates	Packing	Contact type
10A	AC600V(50Hz-60Hz)	-25~70Centigrade	≤ 85%	2500V AC, 1min	≤ 50mΩ	Black, green, red, yellow, blue	CE, CCC, RoHS	Standard export packing	N/O, N/C, N/O+N/C, N/O+N/O

Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.

Yueqing Lovadon Electric Co., Ltd wsa founded in 2012, located in Liushi Chandong Industrial Zone where is near the national scenery area-Yandang Mountain. Our company covers an area of 500m² And has around 30 staff members. It has advanced automation equipment and testing equipment, with a number of high-education management team and staffs. The company speciallized in manufacturing low voltage and high voltage electrical product such as Circuit Breaker, Contactors, Distrubition Boxes, Automation products, Switches, Power source, Lightning arrester, Composite suspension insulator, and so on. Guaranteeing stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets.
