High Voltage High Output Three Phase Asynchronous Induction Motor

Name: High Voltage High Output Three Phase Asynchronous Induction Motor
Brand: all-electronics-online.com
SKU: 805373135
Availability: InStock
Rating: 4.4 (133 reviews)

Price:	US $ 8000-200000/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	1MC0
Power Range:	220kw-3150kw
Shaft Height (mm):	355-560
Poles:	2,4,6,8
Voltage:	6kv/50Hz,10kv/50Hz
Cooling:	IC611/IC81W/IC01
Degree Of Protection:	IP54(IC611/IC81W);IP23(IC01)
Efficiency:	Grade 2 (GB30254-2013) or High Efficiency
Mounting:	Imb3
Frame Material:	Steel Welded
Ambient Temperature:	-15ºC ~ 40ºC
Number Of Stator:	Three-Phase
Function:	Driving
Certification:	Ce
Brand:	Gdly

Product Description

Motor Basic Information
1.Specifications

Power range (kW)	220kw-3150kw
Poles	2,4,6,8
Shaft height (mm)	355-560
Voltage	6kV/50Hz,10kV/50Hz
Thermal Class	155 (F)
Cooling	IC611/IC81W/IC01
Degree of protection	IP54(IC611/IC81W);IP23(IC01)
Frame material	Steel welded
Mounting	IM B3
Efficiency	(GB30254-201) Efficiency Grade 2 (GB30254-2013) or High efficiency level for government subsidy
Bearings	Local high-end(import brand as option)

2.Operating Conditions
1MC0 Motor Standard configuration is suitable for the following working conditions

Rated Voltage	10kV,6kV±5%
Rated Frequency	50Hz±2%
Ambient Temperature	-15ºC ~ 40ºC
Altitude above sea level	1000m No higher than 1000m
Duty Type	S1 Continuous operation S1

Technical Features
• High efficiency.
• Siemens MICALASTIC® Insulation system.
• VPI impregnation.
• High reliable bearing design, nonstop re-greasing and used grease disposal.
• Compact structure, high power density.
• Modular design.
• Various options, possible for customization.
• VSD design.
• Special design adaption.
• Engineering possible for special working conditions.

Applications

1MC0 high voltage three phase asynchronous high efficiency motor is a new modular design for both general applications and special requirements. The motor complies with efficiency grade 2 (GB30254-2013).
1MC0 is an ideal drive source for mechanical machineries such as fan, pump, compressor, winch, centrifugal, crusher and rubber & plastics.

Our Office Block

Team

Guangdong Lingyi Industrial Technology Co., Ltd set up since 1997, with 20 years development, we become one of the best companies in the industry for mechanical and electrical products system integration, logistics service and investment. The company has set up 21 subsidiaries located in southern, central, eastern and northern China, .

The products categories include:

1, Transmission Products: High and low voltage electric motors, geared motors, gear boxes, bearings, inverter and complete electrical cabinets

2, Automation Products: Automation systems, motion control, low voltage control products and systems, sensor and communication products,

3, Power distribution Products: Low-voltage power distribution products, medium voltage circuit breaker, intelligent building system and equipment.

4, Machinery components.

Count on our 20 years industry experiences. Guangdong Lingyi Industrial Technology Co., Ltd give you one-stop industrial products sourcing, procurement, system integration and services, satisfy your different needs in the industry.

We are looking forward to cooperating with you.
