High Voltage Polymer Composite Pin Insulator (FPW-10/2T16-18)

Name: High Voltage Polymer Composite Pin Insulator (FPW-10/2T16-18)
Brand: all-electronics-online.com
SKU: 618783732
Availability: InStock
Rating: 4.9 (87 reviews)

Price:	US $ 8.88/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FPW-10/2T16-18
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	10kv
Bending Load:	2kn
Diameter:	146mm
Creepage Distance:	210mm
Application:	High-voltage
Material:	Composite Polymer
Structure:	Pin Insulator
Size Of Bearing Capacity:	2kn
Brand:	Powlik

Product Description

High Voltage Polymer Composite Pin Insulator (FPW-10/2T16-18)

1.Technical Data
A. Model: FPW-10/2T16-18
B. Rated Voltage: 10KV
C. Highest Voltage: 12KV
D. Bending Load: 2KN
E. Structure Height: 161mm
F. Max. Dia.: 146mm
G. Min. Arcing Distance: 105mm
H. Min. Creepage Distance: 210mm
I. Dia. Of end thread: 16mm (M16)
J. Power Frequency withstand voltage wet: 28KV
K. Full wave lighting impulse withstand voltage: 75KV

Minyang Group Co., Ltd. Mainly specilized in manufacturing and supply busbar trunking system, power transformer, insulator, fuse cutout, voltage stabilizer, surge arrester, power supply, Load breaker switch, isolating switch, switchgear sets, substations, cables and wires etc.

MINYANG GROUP located in Liushi, the electric capital of China, is specialized in developing, manufacturing and distributing power supplies & switchgears, along with about 150 components.

MINYANG GROUP established with 5 specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are enjoying high popularity in Bangladesh, India, UAE, Iran, Saudi, South Africa and Brazil etc.

MINYANG takes "quality is life of enterprise"as its tenet, rewards customers with quality products and perfect services, and creates brilliant future in Chinese electric equipment industry.
