Hmy Series Cast-Iron Housing Three Phase Asynchronous Induction Motor

Name: Hmy Series Cast-Iron Housing Three Phase Asynchronous Induction Motor
Brand: all-electronics-online.com
SKU: 780180745
Availability: InStock
Rating: 5 (145 reviews)

Price:	US $ 45-4300/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	HMY801-2-0.75----HMY355L-10-132
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Efficiency Class:	Ie1
Frame Size:	H80-355
Rated Power:	0.75-315kw
Protection Class:	IP44,IP54,IP54
Frequency:	50Hz,
Rated Voltage:	220/380V,380/660V,230/400
Insulation Class:	B,F,H
Cooling Method:	IC411
Application:	Power Tools
Operating Speed:	High Speed
Number Of Stator:	Three-Phase
Species:	Y, Y2 Series Three-Phase
Casing Protection:	Protection Type
Starting Mode:	Auto-induction Voltage-reduced Starting
Number Of Poles:	2.4.6.8.10.
Certification:	CE
Brand:	Hongma

Product Description

HMY Series Cast-Iron Housing Three Phase Asynchronous Induction Motor
HMY series motor is totally enclosed and fan cooling, three-phase squirrel cage induction motor.It is newly designed in conformity with the relevant rules of IEC and DIN42673 standards.
HMY series motors have outstanding performance, such as high efficiency, energy saving, high starting torque, low noise, little vibration, reliable operation and easy maintenance, etc.
HMY series motors are widely used in many places, where do not exist combustible, explosive or corrosive gas, and without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery and food machines, etc.

GERNANAL INFORMATION
Frame Size:  H71-355
Poles: 2,4,6,8,10 poles
Rated Power: 0.55-315KW
Rated  Voltage: 220/380V,380/660V,230/400V,400V/690V
Frequency:  50HZ,60HZ
Protection Class: IP44,IP54,IP55
Insulation Class:  B,F,H
Mounting Type:B3, B5, B35multi and pad mounting
Ambient Temperature : -20~+40 °C

Model	TYPE	Output_kW	η(%)	Cosφ	r/min	Current_380V	Current_400V	Current_415V	Ts/Tn	Tax/Tn	Is/In
HMY	71M1-2	0.37	70	0.81	2756	1.0	0.9	0.9	2.2	2.2	6.1
HMY	71M2-2	0.55	72	0.82	2792	1.4	1.3	1.3	2.2	2.2	6.1
HMY	80M1-2	0.75	72.1	0.83	2830	1.9	1.8	1.7	2.2	2.3	6.1
HMY	80M2-2	1.1	75	0.84	2830	2.7	2.5	2.4	2.2	2.3	7
HMY	90S-2	1.5	77.2	0.84	2840	3.5	3.3	3.2	2.2	2.3	7
HMY	90L-2	2.2	79.7	0.85	2840	4.9	4.7	4.5	2.2	2.3	7
HMY	100L-2	3	81.5	0.87	2860	6.4	6.1	5.9	2.2	2.3	7.5
HMY	112M-2	4	83.1	0.88	2880	8.3	7.9	7.6	2.2	2.3	7.5
HMY	132S1-2	5.5	84.7	0.88	2900	11.2	10.7	10.3	2.2	2.3	7.5
HMY	132S2-2	7.5	86	0.88	2900	15.1	14.3	13.8	2.2	2.3	7.5
HMY	160M1-2	11	87.6	0.89	2930	21.4	20.4	19.6	2.2	2.3	7.5
HMY	160M2-2	15	88.7	0.89	2930	28.9	27.4	26.4	2.2	2.3	7.5
HMY	160L-2	18.5	89.3	0.90	2930	35.0	33.2	32.0	2.2	2.3	7.5
HMY	180M-2	22	89.9	0.90	2940	41.3	39.2	37.8	2	2.3	7.5
HMY	200L1-2	30	90.7	0.90	2950	55.8	53.0	51.1	2	2.3	7.5
HMY	200L2-2	37	91.2	0.90	2950	68.5	65.1	62.7	2	2.3	7.5
HMY	225M-2	45	91.7	0.90	2970	82.8	78.7	75.9	2	2.3	7.5
HMY	250M-2	55	92.1	0.90	2970	100.8	95.8	92.3	2	2.3	7.5
HMY	280S-2	75	92.7	0.90	2970	136.6	129.8	125.1	2	2.3	7.5
HMY	280M-2	90	93	0.91	2970	161.6	153.5	148.0	2	2.3	7.5
HMY	315S-2	110	93.3	0.91	2980	196.9	187.0	180.2	1.8	2.2	7.1
HMY	315M-2	132	93.5	0.91	2980	235.7	223.9	215.8	1.8	2.2	7.1
HMY	315L1-2	160	93.8	0.92	2980	281.7	267.6	257.9	1.8	2.2	7.1
HMY	315L2-2	200	94	0.92	2980	351.4	333.8	321.7	1.8	2.2	7.1
HMY	355M-2	250	94.0	0.92	2980	439.2	417.3	402.2	1.6	2.2	7.1
HMY	355L-2	315	94.0	0.92	2980	553.4	525.8	506.8	1.6	2.2	7.1
HMY	71M1-4	0.25	65.0	0.74	1347	0.8	0.8	0.7	2.1	2.2	5.2
HMY	71M2-4	0.37	67.0	0.75	1340	1.1	1.1	1.0	2.1	2.2	5.2
HMY	80M1-4	0.55	71.0	0.75	1390	1.6	1.5	1.4	2.4	2.3	5.2
HMY	80M2-4	0.75	72.1	0.76	1390	2.1	2.0	1.9	2.3	2.3	6
HMY	90S-4	1.1	75	0.77	1390	2.9	2.7	2.6	2.3	2.3	6
HMY	90L-4	1.5	77.2	0.79	1390	3.7	3.6	3.4	2.3	2.3	6
HMY	100L1-4	2.2	79.7	0.81	1410	5.2	4.9	4.7	2.3	2.3	7
HMY	100L2-4	3	81.5	0.82	1410	6.8	6.5	6.2	2.3	2.3	7
HMY	112M-4	4	83.1	0.82	1435	8.9	8.5	8.2	2.3	2.3	7
HMY	132S-4	5.5	84.7	0.83	1440	11.9	11.3	10.9	2.3	2.3	7
HMY	132M-4	7.5	86	0.84	1440	15.8	15.0	14.4	2.3	2.3	7
HMY	160M-4	11	87.6	0.84	1460	22.7	21.6	20.8	2.2	2.3	7
HMY	160L-4	15	88.7	0.85	1460	30.2	28.7	27.7	2.2	2.3	7.5
HMY	180M-4	18.5	89.3	0.86	1470	36.6	34.8	33.5	2.2	2.3	7.5
HMY	180L-4	22	89.9	0.86	1470	43.2	41.1	39.6	2.2	2.3	7.5
HMY	200L-4	30	90.7	0.86	1470	58.4	55.5	53.5	2.2	2.3	7.2
HMY	225S-4	37	91.2	0.87	1480	70.9	67.3	64.9	2.2	2.3	7.2
HMY	225M-4	45	91.7	0.87	1480	85.7	81.4	78.5	2.2	2.3	7.2
HMY	250M-4	55	92.1	0.87	1480	104.3	99.1	95.5	2.2	2.3	7.2
HMY	280S-4	75	92.7	0.87	1480	141.3	134.2	129.4	2.2	2.3	7.2
HMY	280M-4	90	93	0.87	1480	169.0	160.6	154.8	2.2	2.3	7.2
HMY	315S-4	110	93.3	0.88	1490	203.6	193.4	186.4	2.1	2.2	6.9
HMY	315M-4	132	93.5	0.88	1490	243.8	231.6	223.2	2.1	2.2	6.9
HMY	315L1-4	160	93.8	0.89	1490	291.2	276.6	266.6	2.1	2.2	6.9
HMY	315L2-4	200	94	0.89	1490	363.2	345.1	332.6	2.1	2.2	6.9
HMY	355M-4	250	94.0	0.90	1490	449.0	426.5	411.1	2.1	2.2	6.9
HMY	355L-4	315	94.0	0.90	1490	565.7	537.4	518.0	2.1	2.2	6.9
HMY	71M1-6	0.18	56.0	0.66	865	0.7	0.7	0.7	1.9	2	4
HMY	71M2-6	0.25	59.0	0.68	863	0.9	0.9	0.9	1.9	2	4
HMY	80M1-6	0.37	62.0	0.70	890	1.3	1.2	1.2	1.9	2	4.7
HMY	80M2-6	0.55	65.0	0.72	890	1.8	1.7	1.6	1.9	2	4.7
HMY	90S-6	0.75	70	0.72	910	2.3	2.1	2.1	2	2.1	5.5
HMY	90L-6	1.1	72.9	0.73	910	3.1	3.0	2.9	2	2.1	5.5
HMY	100L-6	1.5	75.2	0.75	920	4.0	3.8	3.7	2	2.1	5.5
HMY	112M-6	2.2	77.7	0.76	935	5.7	5.4	5.2	2	2.1	6.5
HMY	132S-6	3	79.7	0.76	960	7.5	7.1	6.9	2.1	2.1	6.5
HMY	132M1-6	4	81.4	0.76	960	9.8	9.3	9.0	2.1	2.1	6.5
HMY	132M2-6	5.5	83.1	0.77	960	13.1	12.4	12.0	2.1	2.1	6.5
HMY	160M-6	7.5	84.7	0.77	970	17.5	16.6	16.0	2	2.1	6.5
HMY	160L-6	11	86.4	0.78	970	24.8	23.6	22.7	2	2.1	6.5
HMY	180L-6	15	88.7	0.81	970	31.7	30.1	29.0	2	2.1	7
HMY	200L1-6	18.5	88.6	0.81	970	39.2	37.2	35.9	2.1	2.1	7
HMY	200L2-6	22	89.2	0.83	970	45.1	42.9	41.3	2.1	2.1	7
HMY	225M-6	30	90.2	0.84	980	60.2	57.2	55.1	2	2.1	7
HMY	250M-6	37	90.8	0.86	980	72.0	68.4	65.9	2.1	2.1	7
HMY	280S-6	45	91.4	0.86	980	87.0	82.6	79.6	2.1	2	7
HMY	280M-6	55	91.9	0.86	980	105.7	100.4	96.8	2.1	2	7
HMY	315S-6	75	92.6	0.86	990	143.1	135.9	131.0	2	2	7
HMY	315M-6	90	92.9	0.86	990	171.2	162.6	156.7	2	2	7
HMY	315L1-6	110	93.3	0.86	990	208.3	197.9	190.7	2	2	6.7
HMY	315L2-6	132	93.5	0.87	990	246.6	234.2	225.8	2	2	6.7
HMY	355M1-6	160	93.8	0.88	990	294.5	279.8	269.7	1.9	2	6.7
HMY	355M3-6	200	94	0.88	990	367.4	349.0	336.4	1.9	2	6.7
HMY	355L2-6	250	94.0	0.88	990	459.2	436.2	420.5	1.9	2	6.7
HMY	80M1-8	0.18	51.0	0.61	630	0.9	0.8	0.8	1.8	1.9	3.3
HMY	80M2-8	0.25	54.0	0.61	640	1.2	1.1	1.1	1.8	1.9	3.3
HMY	90S-8	0.37	62.0	0.61	660	1.5	1.4	1.4	1.8	1.9	4
HMY	90L-8	0.55	63.0	0.61	660	2.2	2.1	2.0	1.8	2	4
HMY	100L1-8	0.75	71.0	0.67	690	2.4	2.3	2.2	1.8	2	4
HMY	100L2-8	1.1	73.0	0.69	690	3.3	3.2	3.0	1.8	2	5
HMY	112M-8	1.5	75.0	0.69	680	4.4	4.2	4.0	1.8	2	5
HMY	132S-8	2.2	78.0	0.71	710	6.0	5.7	5.5	1.8	2	6
HMY	132M-8	3	79.0	0.73	710	7.9	7.5	7.2	1.8	2	6
HMY	160M1-8	4	81.0	0.73	720	10.3	9.8	9.4	1.9	2	6
HMY	160M2-8	5.5	83.0	0.74	720	13.6	12.9	12.5	2	2	6
HMY	160L-8	7.5	85.5	0.75	720	17.8	16.9	16.3	2	2	6
HMY	180L-8	11	87.5	0.76	730	25.1	23.9	23.0	2	2	6.6
HMY	200L-8	15	88.0	0.76	730	34.1	32.4	31.2	2	2	6.6
HMY	225S-8	18.5	90.0	0.76	730	41.1	39.0	37.6	1.9	2	6.6
HMY	225M-8	22	90.5	0.78	740	47.4	45.0	43.4	1.9	2	6.6
HMY	250M-8	30	91.0	0.79	740	63.4	60.2	58.1	1.9	2	6.6
HMY	280S-8	37	91.5	0.79	740	77.8	73.9	71.2	1.9	2	6.6
HMY	280M-8	45	92.0	0.79	740	94.1	89.4	86.1	1.9	2	6.6
HMY	315S-8	55	92.8	0.81	740	111.2	105.6	101.8	1.8	2	6.6
HMY	315M-8	75	93.0	0.81	740	151.3	143.7	138.5	1.8	2	6.6
HMY	315L1-8	90	93.8	0.82	740	177.8	168.9	162.8	1.8	2	6.6
HMY	315L2-8	110	94.0	0.82	740	216.8	206.0	198.5	1.8	2	6.4
HMY	355M1-8	132	93.7	0.82	740	261.0	248.0	239.0	1.8	2	6.4
HMY	355M2-8	160	94.2	0.82	740	314.7	299.0	288.2	1.8	2	6.4
HMY	355L-8	200	94.5	0.83	740	387.4	368.1	354.8	1.8	2	6.4
HMY	315S-10	45	91.5	0.75	590	99.6	94.7	91.2	1.5	2	6.2
HMY	315M-10	55	92.0	0.75	590	121.1	115.1	110.9	1.5	2	6.2
HMY	315L1-10	75	92.5	0.76	590	162.1	154.0	148.4	1.5	2	6.2
HMY	315L2-10	90	93.0	0.77	590	191.0	181.4	174.9	1.5	2	6.2
HMY	355M1-10	110	93.2	0.78	590	229.9	218.4	210.5	1.3	2	6
HMY	355M2-10	132	93.5	0.78	590	275.0	261.3	251.8	1.3	2	6
HMY	355L-10	160	93.5	0.78	590	333.3	316.7	305.2	1.3	2	6


		Mounting Dimensions													Overall Dimensions
		A	B	C	D	E	F	G	H	K	P	M	N	S		T	AB	AC	AD	HD	L
HMY	80M	125	100	50	19	40	6	15.5	80	10	200	165	130	12		3.5	165	175	150	175	290
HYE1	90S	140		56	24	50	8	20	90								180	195	160	195	315
HYE1	90L		125																		340
HYE1	100L	60	140	63	28	60		24	100	12	250	215	180	15		4	205	215	180	245	380
HYE1	112M	190		70					112								245	240	190	265	400
HYE1	132S	216		89	38	80	10	33	132		300	265	230				280	275	210	315	475
HYE1	132M		178																		515
HYE1	160M	254	210	108	42	110	12	37	160	15	350	300	250	19		5	330	335	265	385	605
HYE1	160L		254																		650
HYE1	180M	279	241	121	48		14	42.5	180								355	380	285	430	670
HYE1	180L		279																		710
HYE1	200L	318	305	133	55	140	16	49	200	19	400	350	300				395	420	315	475	775
HYE1	225S(4-8P)	356	286	149	60	110	18	53	225		450	400	350				435	475	345	530	820
HYE1	225M(2P)		311		55	140	16	49													815
HYE1	225M(4-8P)				60		18	53													840
HYE1	250M(2P)	406	349	168					250	24	550	500	450				490	515	385	575	930
HYE1	250M(4-8P)				65			58
HYE1	280S(2P)	457	368	190	65				280								550	580	410	640	1000
HYE1	280M(2P)		419																		1050
HYE1	280S(4-8P)		368		75		20	67.5													1000
HYE1	280M(4-8P)		419																		1050
HYE1	315S(2P)	508	406	216	65		18	58	315	28	660	600	550	24		6	744	645	576	865	1240
HYE1	315M(2P)		457																		1310
HYE1	315L(2P)		508																		1310
HYE1	315S(4-10P)		406		80	170	22	71													1270
HYE1	315M(4-10P)		457																		1340
HYE1	315L(4-10P)		508																		1340
HYE1	355M(2P)	610	560	254	75	140	20	67.5	355		800	740	680				740	750	680	1035	1540
HYE1	355L(2P)
HYE1	355M(4-10P)		560		95	170	25	86													1570
HYE1	355L(4-10P)
