Hoist F21-E1 Industrial Wireless Radio Remote Controls
Price: |
US $ 1/Piece |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
Prod Model: |
F21-E1 |
Product Name: |
Industrial Radio Remote Control |
Unique Code: |
Over 4.3billon Unique ID Codes |
Temperature Range: |
-35ºC-----------+80ºC |
Model No: |
F21-E1 |
Application: |
Hoist |
Signal Transmission: |
IR Remote Control |
Type: |
Button |
Certification: |
CE |
Universal: |
Universal |
Transmission Distance: |
>100m |
Voltage: |
3V |
Battery Type: |
AA Battery |
Material: |
Glass Fiber |
Product Description
Product Description
F21-E1 industrial wireless radio remote control system for bridge craneCompany advantage:1. More than 10 years researching and exporting experience in Radio Remote Control industry.
2. Well and high quality control, all working process according to ISO9001: 2008.
3. CE, FCC & ISO certificates.
4. One year warranty.
5. Sample order acceptable.
6. OEM acceptable Features:
*6 Single speed push buttons +one EMGS button+ one START button + one SWITCH
* control points up to 6
* With the battery voltage alarm device to cut off the circuit when voltage is insufficient.
* with the Rotate key switch to guarantee the safety.
* set the internal functions by computer interface
* up/down, east/west, south/north push button can be set start, close, speed up, jump strokes, ordinary etc
radio remote control
Specification:Control distance | Up to 100m |
Unique code | Over 4.3billon unique ID codes. |
Temperature | -35° C~+80° C |
Enclosure protection class | IP65 |
Transmitter power | DC3v |
Receiver powder | AC 380v/ 36v/220V or DC12V/24V |
Output capacity | Full sealed relay output with 5 amperes (using ac 250v/10A relay, 5 amp fuse) |
Standard configuration:
One transmitter;
One receiver;
One 1m cable connect with receiver
One operation and maintain manual.
Application:
Single hook electric cable hoist, monorails, single speed electric hoist or electric single speed hoist crane, and used for the industrial remote control which are under 6 connection.
About us:HeNan Yuding Electronics Corp., Ltd, established in August. 2010 ,is a professional manufacturer in industrial crane radio remote control .Our headquarter is in Zhengzhou, Henan province,China.Our main products are :F21 Series radio remote controls ,F23 series radio remote controls ,F24-60 Dual Joystick radio remote control .All these remote controls are easy to operate to keep workers safe and productive.All products have got CE ,ISO & FCC Certificate .Quality is company's life. From the raw material testing, manufacturing, aging test and assembly , Each process are operated according to ISO9001:2008 & international quality control system to guarantee the best quality.With competitive price ,excellent quality and good after-sales service , Our Internal customers are covered Over 400 cities of 33 provinces.We also have built long-term business relationship with foreign customers.Welcome to contact us at any time .We surely to supply you the best quality ,best offer and best service
Henan Dirk Electronic Co. Ltd (former Henan Yuding Electronics Crop., Ltd) is an industrial radio remote controls manufacturer in China. Established in August, 2010, With more than 10 years experience on this industrial remote control system business area. Headquartered in Zhengzhou, Henan province. Dirk has so many experts in the industrial radio remote controller area to assure quality and productivity, Dirk are becoming one of the leading companies in this industry in China.
Our main products is: F21 Series radio remote controls, F23 series radio remote controls, F24-60 Dual Joystick radio remote control and explosion-proof remote controls. All these remote controls are easy to operate to keep workers safety and Efficient. All our products are CE & FCC & ISO Certificate.
Quality is company's life. From the raw material testing, manufacturing, aging test and assembly, Each process are operate according to ISO9001: 2008 & international quality control system to guarantee the products quality. Competitive price with excellent quality and good after-sales service make our Internal customers are covered Over 400 cities of 33 countries. We also have built long-term business relationship with the foreign customers.
We here sincerely hope to establish partnership with you and your esteem company.
