Home Use Modified Sine Wave Solar DC AC Inverter with 12V/24V
Price: |
US $ 35/Piece |
Min Order: |
5/Piece |
Pay Type: |
L/C,T/T,Western Union,Money Gram |
Prod Model: |
Nature Star Series |
Net Weight (Kg): |
2.62 |
Output Voltage: |
220/230/240VAC (+10% / -18%) |
Output Frequency: |
50Hz or 60Hz (Auto Detection) |
Product Description
Modified Sine Wave Solar Inverter Controller Nature Star Series 1000VA-2000VAPower Range: 1K-2KVA
1): Auto Switch AC to DC.
2):Automatic charging Function.
3): Over-load protection.
4):Full automatic and silent operation.Key Features
- Inverter with Modified Sine Wave Output.
- Built-in PWM Solar Charge Controller.
- High Frequency Inverter Model.
- Auto Switch AC to DC.
- Digital LCD Screen, and audible and visual alarm.
- Automatic charging Function.
- Optional input voltage range.
- Over-load protection.
- Automatic restart.
- Three-steps intelligent charging control to recharging.
- Full automatic and silent operation.
ApplicationHome & Office appliances, Solar power systems etc.
Full Protection:Protection for low battery voltage, overload, output short circuit and overtemperature restrain surge interference, eliminate noise, protection forthunderstriking, providing reliable power to the home appliances.
Technical SpecificationMODEL | NS1000 | NS2000 |
CAPACITY | VA/W | 1000VA/720W | 2000VA/1300W |
NOMINAL BATTERY VOLTAGE | 12VDC | 24VDC |
LINE MODE |
INPUT | Nominal Voltage | 220/230/240VAC |
Voltage Range | 170-280VAC (Narrow Range) |
90-280VAC (Wide Range) |
OUTPUT | Voltage | 220/230/240VAC |
Frequency | 50Hz/ 60Hz |
Output Waveform | Following the Utility |
EFFICIENCY | >95% (full load, battery full charged) |
TRANSFER TIME | 15ms Typical, 40ms Max. |
BACKUP MODE |
OUTPUT | Voltage | 220/230/240VAC (+10% / -18%) |
Frequency | 50Hz or 60Hz (Auto detection) |
Output Waveform | Modified Sine Wave |
EFFICIENCY | | >80% |
OVERLOAD PROTECTION | 1min@>110%, 20s@>120%, 0s@>150% |
PROTECTION | Discharge, over-charged, over-loading, over-temperature, short-circuit protection |
BATTERY CHARGER (powered by AC) |
CHARGING ALGORITHM | 3-step charging |
AC CHARGING MODE | 15Amp / 20Amp Selectable | 10Amp |
FLOATING CHARGING VOLTAGE | 13.7V | 27.4V |
OVERCHARGING VOLTAGE | 16V | 32V |
SOLAR BATTERY CHARGER |
MAX. INPUT POWER | 450W | 900W |
CHARGING CURRENT | 40Amp |
NOMINAL BATTERY VOLTAGE | 12V | 24V |
OPTIMAL WORK VOLTAGE RANGE | 15V~18V | 30V~36V |
MAX. PV INPUT VOLTAGE | 55V |
MAX.PV INPUT CURRENT | 40 Amp |
GENERAL |
PHYSICAL | Dimension (D*W*H) | 275mm*226mm*85mm |
Net Weight (kg) | 2.62 | 2.76 |
ENVIRONMENT | Operating Environment | 0- 50ºC, 5%-90 % relative humidity |
(non-condensing) |
Storage Environment | 15ºC to 55ºC to 55ºC,5% to 95% humidity |
(non-condensing) |
Noise Level | Less than 50dB |
*Specifications are subject to change without prior notice. |
