Hor Sell Pure Sine Wave DC-AC Power Inverter & Converter

Name: Hor Sell Pure Sine Wave DC-AC Power Inverter & Converter
Brand: all-electronics-online.com
SKU: 817665175
Availability: InStock
Rating: 4.7 (100 reviews)

Price:	US $ 140-150/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SNC-1000W

Product Description

Function & Characteristic
1.Input Voltage Range of 12V DC or 24V DC
2.Output Voltage Range of 115V AC or 230V AC
3.For use in cars,boats,trucks,trailers and mobile homes.
4.Take the power inverter to camping and get AC power for lamps,radios or TVs.
5.In an emergency such as blackout,attach the power inverter to your car battery or portable battery and get power to run your appliances.
6.Ultra-Compact Metal Housing
Small and rugged;stored easily in any tool box,briefcase or glove compartment.
7.Low-Battery Alarm/Shutdown
Automatically detects low voltage and shuts down to protect your battery.
8.Integrated Fuse Protection
Protects your battery and power inverter from damage due to outlet overload.

Model	SNC-2000
Max continuous power	2000W
Peak load power rate	4000W
Wave form	pure sine wave
No load current draw	<0.8A
Input DC voltage range	12V(10V-15V) OR 24V(20V-30V)
Output voltage range	230V +/- 10% or 110V +/- 10%
Output frenquency range	50+/-2HZ OR 60+/-2HZ
USB output	DC 5V 500MA
Max outer temperature	<65°C
Max power efficiency	>85%
High voltage cut off level	15.5V+/-0.5V OR 31+/-1V
Low voltage alarm level	10.5V+/-0.5V or 21V+/-1V
Low voltage cut off level	10V+/-0.5V OR 20V+/-1V
Overload and short-circuit protection	YES
Automatic switch	YES
Built-in cooling fan	YES
Product Size	46015090 mm
N.W	4.98kg/pc

Charge current	15A
THD	<5%

Protection Function:
-Low voltage alarm & Shutdown
·Over voltage protection
·Overload protection
·Over temperature protection
·Short circuit protection
·Reverse Polarity protection
·Soft start
·Auto.reset after being in protected
·Grounding protection

Founded in 2005, SUNKAX Technology Limited is a leading manufacturer and exporter for clean power, such as solar inverter, step up/down voltage transformers, consumer electronics (travel charger adaptors, USB Chargers, output power distribution board, etc. ).

Our products are exported to different countries all over the world, be popular in market for high quality, attractive packing, favorable price, and also excellent service.

With a 19, 000 factory, 8 production lines and over 150 well-trained workers, we turn out 90, 000 units monthly. All our products for export must strictly pass IQC inspections on critical components, 100% online testing, under loading and burn-in testing

SUNKAX has been a pioneer of technology. Back in 2005, we explored the key technology of aluminum transformer production and became the first aluminum transformer supplier

In the automatic voltage regulator field, we developed our own high performance MCU controlled circuit and have obtained several registered patents for our products. We developed air-conditioners stabilizers the best solution to meet your demand.

In inverter/UPS field, We are the 1st to invent toroidal inverters. Which have outstanding advantage of low idle current, low electromagnetic interference, long back-up time and high efficiency. Equipped 32-bit speed CPU control with accurate detection and unique C. R. G. O toroidal transformers, including our solar integrated inverters, all core technology are developed by own R&D team, which makes us one of few factories who holds the key technology.

In guidance of strong R&D team, we are able to produce the exceptional reliable products with the help of skillful working staff, comprehensive quality system and advanced equipments such as newest wave(flow) soldering, and burn-in testing line.

Ongoing research and being creative is what keeping our products at the top of our industry.

Our quality policy:

Everyone participates, continuous improvement, innovation.

Our management idea:

Based on good staff, concentrating on quality and efficiency, keeping on providing customers with excellent service.

Welcome to contact us today for your next OEM/ODM project.
