Hot! Carling Style Car 12V/ 24V LED Rocker Switch

Prod Model:	MAIYU
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max. Current:	DC20A\10A AC 10A \16A
Max. Voltage:	DC12V\24V AC 250V\125V
Rating Ampere:	DC20A\12V 10A\24V
Rating Current:	AC10A\250V 16A\250V
Function:	on-off
Grade:	IP68
Warranty:	12 Months
Usage:	Electrical Appliance
Standard:	Standard
Lamp:	With Lamp
Certification:	CE
Condition:	New
Color:	Red/Blue/Green/White/Orange

Product Description

  New images 12V 20A dual LED Light Rocker Switch Carling Style Boat Car Rocker Switch

Details and the Specifications:

1.Abs plastic panel
2.waterproof rocker switch
3.500000 Mechanical Life
4. Process can be screen printing and laser carving
5. It has a face surface size of 0.90' x 1.92' and uses a standard din size mounting hole. Cutout Dimensions are 0.83' x 1.45'.

 These high quality 12 volt Rocker switch is a single throw ON - OFF switch designed to operate your 12 volt accessories. They have a face surface size of 2' (50mm) x 1' (25mm) and uses a standard din size mounting hole of 1.41' (36mm) x .86' (22mm) this is the standard size of most switch holes in modern vehicles, however it is best to check your particular hole size if unsure.



Single Pole Single Throw ON-OFF switch.
12VDC 20Amps, 24VDC 10Amps 125VAC 16Amps, 250V DA10Amps.
Black hard surface rocker.
Two LEDs in the switch.
Upper LED is ON only when the switch is turned ON.
Lower LED is independent.
Both LEDs have separate grounds.
Same size as the Carling and ARB switches.
Rated 16A 12V.
No rear barriers between terminals.

Product Description
Specification :
Model:8-30v Waterproof LED Backlight 5 Gang blue LED Rocker Switch Panel Material Description: High quality ABS
Installation: Pre-wired
Switches Available: 6 Gang

Rocker Switch: 6
Loop Circuit: ON-OFF
Switch System: Water-resistant enclosed Rocker switch
Rating: AC 125V 16A,250V 10A;DC 12V 20A,24V 10A
electric Strength: AC 1500V 1minute
Operating Temperature: -25degree to 80degree
Electrical Life: 10000 make and break cycles at full load
IP Rating: IP67
Package included
1 x Digital Voltmeter+12V power Socket +Double USB Power Charger Adapter aluminum Flush Mount blue 5 gang rocker switch Panel Black RV Car Boat
