Hot Sale Electrolytic Capacitor 22000UF 250V

Name: Hot Sale Electrolytic Capacitor 22000UF 250V
Brand: all-electronics-online.com
SKU: 800223875
Availability: InStock
Rating: 4.4 (44 reviews)

Price:	US $ 0.2666-0.2999/Piece
Min Order:	5000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	22000uf 250v
Operating Temperature Range:	-40~105 Degree
Type:	Aluminum Electrolytic Capacitor
Application:	Automobile
Package Type:	Through Hole
Capacitance:	>100uf

Product Description

Product Description
CBB60 are non-inductively wound with metalized polypropylene film as the dielectic/electrode with "UL" leads and encapsulated in a plastic case sealed with epoxy resin.
FEATURES:
Box type providea the identical outer appearcace
Vory lou loss at high frequency,suitable for high current
High insulation resistance,longlife,self-healing
Applicable to the start-up and operation of 50HZ (60HZ) single-phase motor

SPECIFICATIONS:

Reference Standard	GB3667(IEC 60252)
Climatic Category	70ºC
Rated Voltage	250VAC~630VAC
Capacitance range	1uF--100uF
Capacitance tolerance	±5%(J),Y2: ±10%(K), ±20%(M)
Voltage Proof	1.5Ur(5S);2000VAC(5S)
Dissipation Factor	≤0.4%
Insulation resistance	≥4000S

Rated Cap.	D	H	Part Number	Rated Cap.	D	H	Part Number	Rated Cap.	D	H	Part Number	Rated Cap.	D	H
Rated Cap.	mm	mm	Part Number	Rated Cap.	mm	mm	Part Number	Rated Cap.	mm	mm	Part Number	Rated Cap.	mm	mm
1uF	25	48		13.5uF	35	58		0.5uF	25	48		10.0uF	30	72
1.5uF	25	48		14.0uF	35	58		1.0uF	25	48		10.0uF	35	58
2.0uF	25	48		15.0uF	35	58		1.5uF	25	48		11.0uF	35	72
2.5uF	25	48		16.0uF	35	72		2.0uF	25	48		12.0uF	35	72
3.0uF	25	48		17.5uF	35	72		2.5uF	25	48		12.5uF	35	72
3.15uF	25	48		18.0uF	35	72		3.0uF	25	48		13.0uF	35	72
3.5uF	25	48		20.0uF	35	72		3.15uF	30	55		13.5uF	35	72
4.0uF	25	48		22.0uF	40	72		3.5uF	30	55		14.0uF	35	72
4.5uF	30	55		25.0uF	40	72		4.0uF	30	55		15.0uF	40	72
5.0uF	30	55		30.0uF	40	72		4.5uF	30	55		16.0uF	40	72
6.0uF	30	55		35.0uF	40	95		5.0uF	30	55		17.5uF	40	72
6.3uF	30	58		40.0uF	40	95		5.5uF	30	55		18.0uF	40	72
7.0uF	30	58		45.0uF	45	110		6.0uF	30	55		20.0uF	40	72
7.5uF	30	58		50.0uF	50	110		6.3uF	30	58		22.0uF	40	95
8.0uF	30	58		60.0uF	55	95		6.8uF	30	58		22.0uF	45	75
9.0uF	30	58		60.0uF	50	110		7.0uF	30	58		25.0uF	40	95
10.0uF	30	58		70.0uF	55	95		7.5uF	30	72		30.0uF	45	95
11.0uF	35	58		70.0u	50	120		7.5uF	35	58		35.0uF	45	95
12.0uF	35	58		70.0u	45	145		8.0uF	30	72		40.0uF	50	110
12.5uF	35	58		80.0u	55	110		8.0uF	35	58		50.0uF	55	95
13.0uF	35	58		100.0u	55	120		9.0uF	30	72		60.0uF	55	120
								9.0uF	35	58

Since 1985, SEMG is one of the leading electronic component manufacturers located in Baoan District, Shenzhen City, China, and has been specializing in designing, researching, developing, manufacturing, exporting and processing professional Aluminum Electrolytic Capacitors, Magnet material, PCBA. Now it's becoming the most reliable and famous supplier in China.

SEMG Electrolytic Capacitors

We offer over 23 series 10 thousand various kinds of capacitors products and monthly output up to 2 millions pieces.

*General Purpose aluminum Electrolytic Capacitors

*Low ESR & High Frequency aluminum Electrolytic Capacitors

*Low Impedance &High Ripple aluminum Electrolytic Capacitors

*Low ESR &Long load life aluminum Electrolytic Capacitors

*High ripple &long load life aluminum Electrolytic Capacitors

*snap-in aluminum Electrolytic Capacitors

*SMD Capacitor

*Solid Capacitors

The capacitors we produced widely used for power supply and LED driver, Ballast, Adaptet, SMPS, Home appliances etc. The annual output is more than 800million electrolytic capacitors a year.

SEMG is a ISO Certificated company, the quality of us had pass, RoHS, Reach, CE etc. And we can design the quality products as the customers needed!

SEMG Smartnoble EMC shielding Material

Smartnoble is a subsidiary company of SEMG, focus on the manufacturing and supplying EMC shielding material with silcone rubber, customized shape, welcome to visit http://www.smartnoble.cn/ for details.

SEMG Printing & Acoustic Fabrics

SEMG provides the high tension and low elongation of polyester mesh, with SGS and MSDS certificates, and applicable to the high precise printing for the industries of printed circuit boards, touch panel, glass and textile, cellphones etc. And also providing the advanced acoustic fabrics, which widely used in the protection of acoustic devices, and perform well to meet customer's demand, with its accurate holes and air current control, and its excellent stability to the different environment.

SEMG PCB Fabrication:

SEMG produces the samples and small volume of High layer and rigid-flex PCB, and big volume of low techology PCB.

1) Manufacturing facilities in China for a total capacity of over 4.0 million FT2/month, building area: 500, 000sq. FT, and typical PCB Equipment includes: Mitsubishi Laser Machines, Horizontal Copper plating, Horizontal Silver plating, Heavy Gold plating, Inner Finger beveling, and Automatic Appearance Inspection, etc.

2) Process Capability: Trace Width 3/3mil for volume production, 2/2mil for prototype, min. Mechanical hole 0.15mm, min. Laser via: 0.1mm.

3) Broad product range with expertise in:

Prototype, medium and high volume production of single-side, 2L, 4L to max. 28L.

Max. HDI capability (4+N+4) PCBs.

High frequency and high performance PCBs

Heavy copper PCBs (up to 12oz inner copper)

Aluminum-based PCBs

4)Certificates: ULNo.: E96016, ISO9000-, ISO/TS16949(Automative),

ISO13485 (Medical) -certified and Bellcore-compliant(Telecom).

5) Global support across different continents.

Other service: R&D of wireless modules

SEMG is focus on the researching and development of wireless modules and products, with WiFi, ZIGBEE, and Blue tooth solutions.
