Hotsale 200watt 2500PPR Encoder AC Servo Motor and Driver

Hotsale 200watt 2500PPR Encoder AC Servo Motor and Driver
Price: US $ 240/Set
Min Order: 1/Set
Pay Type: T/T,Western Union,Paypal
Prod Model: 60ST-M00630A
Rated Power Range: 200watt
Encoder: 2500 PPR
Voltage: 3phase 220V
Control Mode: Position, Velocity, Torque Control
Position Control: Pusle or Inner Register
Velocity Control: -10~+10V Analog or Inner Register
Torque Control: -10~+10V Analog or Inner Register
Protocol: Modbus
Communication Port: RS485
Protection Grade: IP64
Number Of Stator: Three-Phase
Function: Position
Brand: Sevode

Product Description

Feature:
650Hz speed loop response frequency
3 times overload capacity
Low noise and vibration
Very high cost-effective
Build in vibration suppression
Spec. table
Model60ST-M00630A
Rated power200w
Encoder2500 ppr optical encoder
Rated line Voltage220V
Rated line current1.2A
Rated speed3000rpm
Rated torque0.64Nm
Peak torque1.91Nm
BEMF30.9 V/1000rpm
Torque constant0.53Nm/A
Rotor inertia0.175 X10^-4 kg.m^2
Winding resistor6.18 ohm
Winding inductance29.3mH
Electric constant4.74 ms
Weight1.16kg
Protection gradeIP64
Insulation gradeClass F
BrakeOptional





A&R Technology Co., Ltd is located in Shenzhen China. A&R is short for accurate and reliable. Suppling accurate and reliable automation product to customers is our goals and mission. Based on the professional service team, fast delivery, perfect customer service network to help our customers to promote effecient industrial automation process, we are committed to make our customer successful and satisfy.

A&R is addicted to supply AC servo motor&driver, step motor&driver, CNC machine controller for lathe/turning machine, milling/drilling machine, plasma/flame cutting machine etc. To make customer easy to build to retrofit used CNC machine. We make solutions for CNC lathe, milling, cutting machine. You can get a total system that includes AC servo motor and driver(Step motor and driver) neccessary cable and CNC machine controller in a package. Japanese brand servo system such as SANYO denki, Tamagawa servo systems are provided. Scara robot and desktop robot are new business in our business system. It is advanced on cost-effective. In total. We can have wealth choice to customer.

Now we have already built a wide business all over the worlds. That main customer is from Middle East, Southeast Asia, Russia and India. We hope to build a stable business relation ship with you in near future.
