Takfly Communications Co., Ltd. >> Hotselling Sc/Upc to FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord

Hotselling Sc/Upc to FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord

Hotselling Sc/Upc to FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord
Price: US $ 0.9/Piece
Min Order: 10/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: Optical Fiber Patch Cord
Product Name: Fiber Optic Patch Cord
Connector Type: Sc, FC, St, LC,Odc,Iplc,Pdlc, MTRJ, MPO,MTP,Mu,SMA
Length: 3m,5m,10 or Customized
Material: LSZH,PVC,PE,PU
Fiber: G652D,G655,G657A1,G657A2
Warranty: 3 Years
Lead Time: 3 Working Days
Application: Communication
Type: Single-mode Fiber
Connection Structure: FC-SC
Certification: CCC
Sheath Material: PVC or LSZH

Product Description

Hotselling SC/UPC to FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord




Details:
SC-SC fiber patch cord
A patch cord is a fiber optic cable used to attach one device to another for signal routing.
SC stands for Subscriber Connector- a general purpose push/pull style connector. It is a square, snap-in connector latches with a simple push-pull motion and is keyed.

Features:
Low insertion loss, high return loss
High dense connection, easy for operation
High credibility and stability
Good in repeatability and exchangeability

Application:
Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system
Telecommunication
Specification:
Parameter
Unit
FC, SC, LC/ Armoured fiber patch cord


Performance & Specifications
Fiber TypeSMMM
Normal Fiber OD125±0.2um125±0.2um
Connector TypeSC,FC,ST, E-2000, LC, MUMTRJSC,FC,ST, E-2000, LC, MUMTRJ
Insertion loss(Typical)0.2dB0.4dB0.2dB0.4dB
Insertion loss(Max)0.3dB0.5dB0.3dB0.5dB
Return Loss(Typical)PC50dB35-
UPC55dB--
APC65dB--
Mating Durability(500 C)0.2dB
Temperature Stability0.3dB
Operation Temperature-40°C~+85°C
Storage Temperature-40°C~+85°C




Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.

The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.

TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.

Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
