| Prod Model: |
DS-4G754W-SMAMM3M |
| Gain: |
0~5dBi |
| Polarization: |
Vertical |
| Cable: |
RC174 |
| Connector: |
SMA/Ts9/CRC9 |
| Usage: |
Communication Antenna |
| Material: |
Cu |
| Directionality: |
Omnidirectional Antenna |
| Usage Occasion: |
PC |
| VSWR: |
<=2.5 |
Product Description
Index: - Antenna Radiation Pattern
================================================== | Test Item | Procedure | Requirement |
| | | |
| 1. Visual inspection | Applicable methods | follow specification |
| and Dimension | using x5 | |
| Check | magnification | |
| 2. Rapid Changing | -40˚C (30minutes) to | After 2 hours recovery: |
| of Temperature | 90˚C (30minutes); | 1. no visible damage |
| | 24 cycles | 2. Freq. Tol.: < ±5% |
| 3. Damp Heat | 24 hours at 60˚C; | After 2 hours recovery: |
| | 90 ~ 95% RH | 1. no visible damage |
| | | 2. Freq. Tol. : < ±5% |
| 4. Endurance | 24 hours at 90˚C | After 2 hours recovery: |
| | | 1. no visible damage |
| | | 2. Freq Tol.: < ±5% |
| | | |
Specification | A. Electrical Characteristics | |
| S.W.R.( Tested in PC ) | <= 2.5 @700-2700MHz |
| Typical Antenna Gain | 0-5DBi |
| Radiation Pattern | Omni-Directional(nominal) |
| Polarization | Vertical |
| Impedance | 50 Ohm |
| B. Material | |
| Material of Radiator | CU |
| Cable Length | RG174 Cable |
| Connector Type | SMA Male |
| C. Environmental | |
| Operation Temperature | - 30 ˚C ~ + 85 ˚C |
| Storage Temperature | - 30 ˚C ~ + 85 ˚C |
2. S Parameter Test Data
3. Antenna Radiation Pattern Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 5071B Received Antenna: 0.7 ~ 6.0 GHz for Gain Calibration Double Ridged Horn Antenna
