Shenzhen UPSEN Electronic Co., Ltd. >> Hybrid Pure Sine Wave Inverter Controller Rainbow Star Series 1000va-5000va

Hybrid Pure Sine Wave Inverter Controller Rainbow Star Series 1000va-5000va

Hybrid Pure Sine Wave Inverter Controller Rainbow Star Series 1000va-5000va
Price: US $ 50-300/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union,Money Gram
Prod Model: RS series
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color: Green
Frequency Range: 50 Hz/60 Hz (Auto Sensing)
AC Voltage Regulation: 230 VAC ± 5%
Voltage: 208/220/230/240 VAC
Phase: Single
Power Source: Electric Power & Solar Power & Wind Power

Product Description


Hybrid Pure Sine Wave Inverter Controller Rainbow Star Series 1000Va-5000Va
Key Features

Pure sine wave inverter                                                                                                                                               High frequency full bridge design .
Built-in MPPT solar charge controller
Selectable input voltage range for home appliances and personal computers
Selectable charging current based on applications
Configurable AC/Solar input priority via LCD setting
Compatible to mains voltage or generator power
Parallel operation with up to 6 units only available for 4KVA/5KVA
Auto restart while AC is recovering
Overload and short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
Optional Remote Control Panel available


Application                                                                                                                                                             Supply the reliable long back up time power for the home appliances
and office appliances Solar power systems etc.
Technical Specification
ModelRS1000 RS2000 RS3000 RS4000 RS5000
RATED POWER1000VA/800W2000VA/1600W3000VA/2400W4000VA/3200W5000VA/4000W
INPUT
Voltage208/220/230/240 VAC
Selectable Voltage Range170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
Frequency Range50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)230 VAC ± 5%
Surge Power2000VA4000VA6000VA8000VA10000VA
Efficiency (Peak)90~93%93%
Transfer Time10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
WaveformPure sine wave
BATTERY & AC Charger
Battery Voltage24VDC48 VDC
Floating Charge Voltage27VDC54 VDC
Overcharge Protection30VDC60 VDC
Maximum AC Charge Current20A25 A
SOLAR CHARGER
Maximum PV Array Open Circuit Voltage60VDC/150Vdc (Optional)110VDC/150Vdc (Optional)
Mppt Range @ Operating Voltage25-60Vdc/25-150Vdc (Optional)60-110Vdc/60-150Vdc (Optional)
Maximum Solae Charge Current40/60A60A
Max Efficiency  >96%
Standby Power Consumption2W
PHYSICAL
Dimension, D x W x H (mm)350 x 130 x 340380 x 130 x 465
Net Weight (kgs)7.47.6812.513.5
OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature0°C - 55°C
Storage Temperature-15°C - 60°C







Shenzhen UPSEN Electronic Co., Ltd. Which is located in south of China, Shenzhen City, close to Pearl of the Orient HK, with beautiful environment and convenient transport.

We are a private high-tech enterprise integrating researching & development, production & operation and technical services as a whole, which is specialized in Electric, Electronic and Energy fields for a long time. Our main products are UPS Power, Inverter Power, Battery Power, Solar&Wind Power. We are dedicated to offer quality power and power solution for Data-center, Telecom, Bank, Hospital, Transportation, Industry, Army, Security, and civil & office area etc. Moreover, we have mastered the core technology of power products through our independent research, we are one of few domestic enterprises which can meet the customers' customized requirements, and provide professional power solutions.

We already past ISO9001 international quality system certification, and established a complete quality system ranging from material source, process, assembling to testing. All our products are with CE Certificate, which exported to more than 30 countries and areas, like Australia, Europe, Africa, North America, South America, the Middle East, central Asia, southeast Asia etc.

We will always offer excellent quality and products to customers. Hope to make Integrity and Double-Win business with you, and to be your professional power supplier and solve your any power problems. We are sure UPSEN can achieve more successes with our efforts and your support.
