IC Integrated Circuit of Positive Voltage Regulator L78m12cdt-Tr

Name: IC Integrated Circuit of Positive Voltage Regulator L78m12cdt-Tr
Brand: all-electronics-online.com
SKU: 802037515
Availability: InStock
Rating: 4.9 (138 reviews)

Price:	US $ 0.1167/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	L78M12CDT-TR
Category:	Positive Voltage Regulator
Output Type:	Fixed
Maximum Input Voltage (V):	35
Output Voltage (V):	5
Output Current:	0.5A
Minimum Input Voltage (V):	7
Operating Temperature:	0~150

Product Description

Positive voltage regulators
Features
Output current to 0.5 A
Output voltages of 5; 6; 8; 9; 12; 15; 18; 24 V
Thermal overload protection
Short circuit protection
Output transition SOA protection

Description
The L78Mxx series of three-terminal positive
regulators is available in TO-220, TO-220FP,
DPAK and IPAK packages and with several fixed
output voltages, making it useful in a wide range
of applications. These regulators can provide
local on-card regulation, eliminating the
distribution problems associated with single point
regulation. Each type employs internal current
limiting, thermal shut-down and safe area
protection, making it essentially indestructible. If
adequate heat sinking is provided, they can
deliver over 0.5 A output current. Although
designed primarily as fixed voltage regulators,
these devices can be used with external
components to obtain adjustable voltage and
currents.
