HK Hushun Group Co., Ltd. >> Illuminated Rocker Switch, Microswitch (JR-101-1F)

Illuminated Rocker Switch, Microswitch (JR-101-1F)

Illuminated Rocker Switch, Microswitch (JR-101-1F)
Price: US $ 0.21/Piece
Trade Terms: FOB,CFR
Min Order: 1000/Piece
Pay Type: T/T,Western Union
Prod Model: JR-101-1F
Markets: North America,South America,Eastern Europe,Southeast Asia,Mid East,Western Europe
OEM: Yes
MOQ: 10k
Shipment Of Terms: CIF,FOB,EXW
Finish: Nickel Plating
Type: Normal Open
Usage: Reset Button
Kind: Single-pole on-off Switch

Product Description


Product Details
Basic Info.Illuminated Rocker Switch (JR-101-1F)
Model NO.:JR-101-1F

Usage:Control Button, Reset Button
Kind:Single-pole on-off Switch

Type:Normal Open
Material:Zn-Al. Alloy

Function:Momentary
Contact:Normal Open

Termminal:Pin (2X0.5mm) / Screw
Color:Red, Green, Yellow, Orange, Blue, Black

Size:Dia 12mm
Export Markets:Global
Additional Info.
Trademark: OEM

Packing:50PCS/Box
Standard:CE, ROHS, REACH

Origin:Dongguan
HS Code:85365000

Production Capacity:50000PCS/Month
Product Description

HS-ES-001
Φ12mm diameter
2A/48VDC
1NO, Momentary
Domed profile
Crust material: Zn-Al. alloy
Head Color: Red, Green, Yellow, Blue, White, Black.
IP Degree: IP65




Model
JR-101-1F
Illuminated OptionsNon-illuminated
Front ShapeRoundSquare
Terminal TypeScrew / Pin (2.8x0.5mm)
Max. Switch Rating2A/48V DC
Contact Resistance≤50mΩ
Insulation Resistance≥1000mΩ
Dielectric Strength2000VAC
Operation Temp.-20°c ~ +55°c
Mechanical Life1, 000, 000cycles
Electrical Life20, 000cycles
Contact MaterialSilver Alloy
Torque5~14Nm
Operation Pressure5N
IP DegreeIP65 / IK08
Material
ActuatorStainless Steel  / Brass / PBT
BodyStainlessSteel / Brass / Zin-Al Alloy
BasePBT
ColorRED, GREEN, YELLOW, ORANGE, BLUE, WHITE, BLACK
Actuator(Zn-Al.alloy)
