Indoor Single-Mode Breakout Fiber Optic Cable (GYDA009)

Name: Indoor Single-Mode Breakout Fiber Optic Cable (GYDA009)
Brand: all-electronics-online.com
SKU: 684714362
Availability: InStock
Rating: 4.3 (68 reviews)

Price:	US $ 0.599-0.68/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	2000/Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GYDA009
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cable Dimension:	15.0mm
Central Strength Member:	FRP
Yarn:	Kevlar
Tight-Buffer:	0.9mm
Application:	Communication
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	Glass Fiber
Brand:	Neutral
Sheath Material:	PVC or LSZH

Product Description

Indoor 24 Cores Single-Mode Breakout Fiber Optic Cable--GYDA009

Application
1. Used for indoor wiring, especially used as breakout cable
2. Used as access building cable
3. Used as interconnect lines of equipments, and used in optical connections in optical communication equipment rooms and distribution frames
4. Used as pigtails and patch cords

Features
1. Good mechanical and environmental performance
2. Flame retardant (or secondary) performance meet the requirements of relevant standards
3. Sheath of the mechanical and physical properties meet the requirements of relevant standards
4. Soft, flexible, convenient, and support the large capacity data transmission
5. Meet the market and the requirements of the users
Options:
Fiber Type:G.652, G.655 or 6.657 single-mode fiber. A1a or A1b, OM3 or OM4 mufti-mode fiber, or other types of fiber;
Jacket Material: Environmental flame retardant polyvinylchloride(PVC), environmental low smoke zero halogen flame retardant palyolefin(LSZH),environmental halogen flame retardant polyolefin(ZRPO), environmental thermasplatic polyurethane(TPU), or other contracted material;
Jacket Color:(Including color of tiber) meets the requirements of relevant standards, or other contracted color;
Cable Dimension: The nominal cable dimension, or other contracted dimension;
Delivery Length: 1 km or 2km, or other contracted length;
Other Requirements: Other contracted special requests.

Items		Specifications
Fiber Count		24
Tight-buffered Fiber	Dimension	850µm±50µm
	Material	PVC
	Color	White
Simplex Cable	Dimension	1.9mm±0.1mm
	Material	LSZH
	Color	\ Yellow\Orange or Aqua
	Strength Member	Kevlar
	Printing Marks	1~24
Central Strength Member	Diameter	3.8mm±0.1mm
	Material	FRP+LSZH
	Color	\ Yellow\Orange or Aqua
Outer Jacket	Dimension	14.5mm±0.5mm
	Material	LSZH
	Color	\ Yellow\Orange or Aqua
