Indoor Sm Distribution Fiber Optic Cable

Name: Indoor Sm Distribution Fiber Optic Cable
Brand: all-electronics-online.com
SKU: 688100722
Availability: InStock
Rating: 4.6 (144 reviews)

Price:	US $ 0.138-0.15/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	2000/Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GJPFJV-4B1.3
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	4.8mm
Fiber Count:	4core
Strength Member:	Kevlar
Jacket Material:	PVC
Type:	Single-mode Fiber
Certification:	ISO9001
Application:	Data Center
Connection Structure:	Indoor Mini Breakout Cable
Core:	2/4/8/12/24/48/72/96/144
Brand:	Geyida
Sheath Material:	PVC/LSZH

Product Description

Indoor 4 Cores SM Fiber Optic Distribution Cable
Application of fiber optic cable
1. Used for indoor wiring, used as distribution cable
2. For device interconnection line, optical distribution frame of optical link as optical communication
Equipment room
3. Used as pigtails and patch cords
4.Used in indoor cabling, especially in poor laying conditions;

Characteristics of fiber optic cable
1. With good mechanical and environmental performance.
2. Flame retardant performance meet the requirements of relevant standards
3. Sheath of the mechanical and physical properties meet the requirements of relevant standards
4. Soft and flexible connection is convenient, and support the large capacity data transmission

Options:
Fiber Type:G.652, G.655 or 6.657 single-mode fiber. A1a or A1b, OM3 or OM4 mufti-mode fiber, or other types of fiber;
Jacket Material: Environmental flame retardant polyvinylchloride(PVC), environmental low smoke zero halogen flame retardant palyolefin(LSZH),environmental halogen flame retardant polyolefin(ZRPO), environmental thermasplatic polyurethane(TPU), or other contracted material;
Jacket Color:(Including color of tiber) meets the requirements of relevant standards, or other contracted color;
Cable Dimension: The nominal cable dimension, or other contracted dimension;
Delivery Length: 1 km or 2km, or other contracted length;

Fiber Count	Cable Dimension(mm)	Cable Weight(kg/km)	Tensile(N)		Crush(N/100mm)		Min.Bend Radius(mm)		Range of Tem(ºC)
			Tensile(N)		Crush(N/100mm)		Min.Bend Radius(mm)
			Long Term	Short Term	Long Term	Short Term	Dynamic	Static
4	5.0	19.0	130	440	200	1000	20D	10D	-20~+60
6	5.2	23.0	130	440	200	1000
8	5.5	26.0	130	440	200	1000
12	6.5	36.5	200	660	200	1000
16	7.5	44.5	200	660	200	1000
24	8.2	54.5	200	660	200	1000
36	9.0	72.0	200	660	200	1000
48	10.5	90.0	200	660	200	1000
Note:	All the values in the table, which are for reference only, are subject to change without notice;
Note:	The minimun bend radius(static) is 5D when G.657 fiber is used.
