Industrial Pressure Transmitter

Prod Model:	Pt 500 Series

Product Description

Stainless steel structure, whole sealing, good Damp-proofing and medium compatibility, suitable for low corrosive medium in many industrial process. We import the key component of circuit from famous international suppliers to ensure the goods quality and advanced technique.
Suitable for pressure measuring and controlling of industrial facility, Irrigation, Chemical industry, Medical, Electric power, air condition. Diamond press machine, metallurgy, water supply to building and so on.

1. Capacity Range: 0~1-150MPa
2. Comprehensive Precision: 0.1%FS, 0.2%FS, 0.3%FS,
0.5%FS, 1.0%FS
3. Output Signal: 4~20mA, 0~5V, 1~5V, 0~10V
4. Use Temp Range: -10~80-150º C
5. Excitation Voltage: 9~36V, if output =4~20mA or 0~5V or1~5V; 15~36V, if output= 0~10V
6. Stability: 0.1%F. S/year
7. Burden Resistance: Electric Current output: ≤ 800Ω Voltage output: ≥ 50KΩ
8. Insulation Resistance: ≥ 2000MΩ 100VDC
9. Effection of Vibration: On 20Hz-1KHz of mechanical shake, Output ≤ 0.1%F. S
10. Defend Grade: IP68
11Process connection: M20× 15 and also designed for Customers' requirements.
