Integrated Circuit CD4093be of Nand Trigger IC

Name: Integrated Circuit CD4093be of Nand Trigger IC
Brand: all-electronics-online.com
SKU: 796700165
Availability: InStock
Rating: 5 (38 reviews)

Price:	US $ 0.18/Piece
Min Order:	300/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	CD4093BE
Logic Family:	CD4000
Logic Function:	Nand
Fabrication Technology:	CMOS
Number Of Elements Per Chip:	4
Number Of Element Inputs:	2-in
Number Of Element Outputs:	1
Operating Temperature Range:	-55 to 125 Degree C
Minimum Operating Supply Voltage (V):	3
Maximum Operating Supply Voltage (V):	18
Maximum Quiescent Current (Ua):	20

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

MANUFACTURER
Texas Instruments

PRODUCT CATEGORY
Gates

DESCRIPTION
NAND Gate 4-Element 2-IN CMOS 14-Pin PDIP Tube

Dump the microprocessor and build your circuit using fundamental logical operations using Texas Instruments' CD4093BE logic gates. This gate has a minimum operating temperature of -55 °C and a maximum of 125 °C. This device comes in tube packaging. This device has a typical operating supply voltage of 3.3|5|9|12|15 V. Its minimum operating supply voltage of 3 V, while its maximum is 18 V.

Specifications
EU RoHS Compliant
Logic Family CD4000
Logic Function NAND
Fabrication Technology CMOS
Number of Elements per Chip 4
Number of Element Inputs 2-IN
Number of Element Outputs 1
Minimum Operating Temperature (°C) -55
Maximum Operating Temperature (°C) 125
Packaging Tube
Minimum Operating Supply Voltage (V) 3
Maximum Operating Supply Voltage (V) 18
Typical Operating Supply Voltage (V) 3.3|5|9|12|15
Maximum High Level Output Current (mA) -4.2(Min)
Maximum Low Level Output Current (mA) 4.2(Min)
Maximum Quiescent Current (uA) 20
Mounting Through Hole
Package Height (mm) 5.08(Max) - 0.51(Min)
Package Length (mm) 19.69(Max)
Package Width (mm) 6.6(Max)
PCB changed 14
Standard Package Name DIP
Supplier Package PDIP
Pin Count 14
Lead Shape Through Hole

Features
• Schmitt-trigger action on each input with no external components
• Hysteresis voltage typically 0.9 V at VDD = 5 V and 2.3 V at VDD = 10 V
• Noise immunity greater than 50%
• No limit on input rise and fall times
• Standardized, symmetrical output characteristics
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V over full package-temperature range, 100 nA at 18 V and 25°C
• 5-V, 10-V, and 15-V parametric ratings
• Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of 'B' Series CMOS Devices"

Applications:
Wave and pulse shapers
High-noise-environment systems
Monostable multivibrators
Astable multivibrators
NAND logic
