Integrated Circuit of Bipolar 12/14/16-Bit ADC IC Ad7656bstz

Name: Integrated Circuit of Bipolar 12/14/16-Bit ADC IC Ad7656bstz
Brand: all-electronics-online.com
SKU: 796955555
Availability: InStock
Rating: 4.6 (72 reviews)

Price:	US $ 13.5/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	AD7656BSTZ

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

FEATURES
6 independent ADCs
True bipolar analog inputs
Pin-/software-selectable ranges: ±10 V, ±5 V
Fast throughput rate: 250 kSPS
iCMOS process technology
Low power
140 mW at 250 kSPS with 5 V supplies
Wide input bandwidth
86.5 dB SNR at 50 kHz input frequency
On-chip reference and reference buffers
Parallel, serial, and daisy-chain interface modes
High speed serial interface
SPI-/QSPI™-/MICROWIRE™-/DSP-compatible
Standby mode: 100 µW maximum
64-lead LQFP

APPLICATIONS
Power line monitoring systems
Instrumentation and control systems
Multi-axis positioning systems
