Integrated Circuit of Drivers or Receivers IC Max232cse+T

Name: Integrated Circuit of Drivers or Receivers IC Max232cse+T
Brand: all-electronics-online.com
SKU: 796633375
Availability: InStock
Rating: 4.7 (107 reviews)

Price:	US $ 0.47/Piece
Min Order:	3000/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MAX232CSE+T

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

General Description
The MAX220-MAX249 family of line drivers/receivers is
intended for all EIA/TIA-232E and V.28/V.24 communications
interfaces, particularly applications where ±12V is
not available.
These parts are especially useful in battery-powered systems,
since their low-power shutdown mode reduces
power dissipation to less than 5µW. The MAX225,
MAX233, MAX235, and MAX245/MAX246/MAX247 use
no external components and are recommended for applications
where printed circuit board space is critical.

Features
Superior to Bipolar
♦ Operate from Single +5V Power Supply
(+5V and +12V-MAX231/MAX239)
♦ Low-Power Receive Mode in Shutdown
(MAX223/MAX242)
♦ Meet All EIA/TIA-232E and V.28 Specifications
♦ Multiple Drivers and Receivers
♦ 3-State Driver and Receiver Outputs
♦ Open-Line Detection (MAX243)

Applications
Portable Computers
Low-Power Modems
Interface Translation
Battery-Powered RS-232 Systems
Multidrop RS-232 Networks

Category	Integrated Circuits (ICs)
Family	Interface - Drivers, Receivers, Transceivers
Manufacturer	Maxim Integrated
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
Type	Transceiver
Protocol	RS232
Number of Drivers/Receivers	2/2
Duplex	Full
Receiver Hysteresis	500mV
Data Rate	120Kbps
Voltage - Supply	4.5 V ~ 5.5 V
Operating Temperature	0°C ~ 70°C
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package	16-SOIC
