Intelligent Differential Pressure / Level / Flow / Density Transmitter for Liquid, Gas (ATEX)
| Price: |
US $ 500-3000/Piece |
| Min Order: |
2/Piece |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
RP1001 |
| Temperature Limits: |
-30~400 Deg. C |
| Vibration Resistance: |
2g up to 500Hz |
| Output: |
2-Wire, 4-20mA Via Hart |
| Fill Fluid: |
Silicone Oil, (Super) High Temp. Silicone Oil |
| Power Supply: |
24V DC |
| Max. Voltage Limited: |
42V DC |
| Amplifier Housing: |
Aluminum with Epoxy Resin Coat |
| Housing Gasket: |
Perbunan (NBR) |
| Electrical Connection: |
M20X1.5 |
| Nuts & Bolts: |
304 Ss |
| Structure Type: |
Monocrystalline Silicon |
| Accuracy Grade: |
0.075%F.S |
| Pressure Range: |
0 to 2kpa~250kpa |
| Certification: |
Atex |
Product Description
Tosilon Intelligent Differential Pressure / Level / Flow / Density Transmitter for Liquid, Gas (ATEX Approved)Design and Manufacturing according to ATEX StandardGeneral DescriptionThe Remote Seal Differential Pressure Transmitter RP1001 is suitable to measure liquid, gas, or steam flow as well as liquid level, density and pressure. RP1001 outputs a 4-20mA DC signal corresponding to the measured differential pressure. Its highly accurate and stable sensor can also measure the static pressure
which can be shown on the integral indicator or remotely monitored via HART communications. Other key features include quick response, remote set-up using communications, self-diagnostics and optional status output for pressure high/low alarm. The range limit is 0-1kPa~2MPa, the flange's working pressure are 1.6/4MPa, 6.4MPa, 10MPa, 150psi, 300psi or 600psi.
Span & Range LimitsSpan
Code | Measuring Range | SWP (Max.) |
| Min. | Max. |
| B | 1kPa | 6 kPa | The flange's
working pressure |
| C | 4 kPa | 40 kPa |
| D | 25 kPa | 250 kPa |
| E | 200 kPa | 2MPa |
| Flange | Nominal
Diameter | The Min.
Measuring Range |
| 1 flange | 2 flange |
| Bulge Sealing | DN 50 / 2" | 16 kPa | 16 kPa |
| DN 80/ 3" | 6 kPa | 1 kPa |
| DN100 / 4" | 6 kPa | 1 kPa |
| Flat Sealing | DN 50/ 2" | 10 kPa | 10 kPa |
| DN 80 / 3" | 6 kPa | 1 kPa |
| DN 100 / 4" | 6 kPa | 1 kPa |
Fill Fluid, temperature limits and the working pressure range| Fill Fluid | Silicone
Oil (S) | High Temp.
Silicone Oil
(H) | Super High
Temp.
Silicone Oil
(U) | Vegetable
Oil (V) |
Density
25 oC | 960
Kg/m3 | 980
Kg/m3 | 1020
Kg/m3 | 937
Kg/m3 |
Temp.
limits | -30~
200 oC | -10~
350 oC | -10~
400 oC | 0~
250 oC |
| |
| Temp. | Working Pressure Range (kPa abs.) |
| 20 oC | >10 | >10 | >10 | >25 |
| 100 oC | >25 | >25 | >25 | >50 |
| 150 oC | >50 | >50 | >50 | >75 |
| 200 oC | >75 | >75 | >75 | >100 |
| 250 oC | | >100 | >100 | >100 |
| 350 oC | | >100 | >100 | |
| 400 oC | | | >100 | |
EMC Performance Table| Items | Test Items | Basic Standard | Test Condition | Performance Level |
| 1 | Radiated Interference (Housing) | GB/T 9254-2008 | 30 MHz~1000 MHz | OK |
| 2 | Conducted Interference
(DC Power Port) | GB/T 9254-2008 | 0.15 MHz~30 MHz | OK |
| 3 | Electrostatic Discharge (ESD)
Immunity | GB/T 17626.2-2006 | 4kV (Line)
8kV (Air) | B |
| 4 | RF Electromagnetic Field
Immunity | GB/T 17626.3-2006 | 10V/m (80 MHz~1 GHz) | A |
| 5 | Frequency Magnetic Field
Immunity | GB/T 17626.8-2006 | 30A/m | A |
| 6 | Electrical Fast Transient Burst
Immunity | GB/T 17626.4-2008 | 2kV/(5/50ns, 5kHz) | B |
| 7 | Surge Immunity | GB/T 17626.5-2008 | 1kV (Line to Line)
2kV (Line to Ground)
(1.2us/50us) | B |
| 8 | Conducted Interference
Immunity induced by RF Field | GB/T 17626.6-2008 | 3V (150 KHz ~ 80 MHz) | A |
Dimensions
