| Prod Model: |
MS Series 10K-200Kva |
| Output Power Factor: |
0.9-1.0 |
| Display: |
Digital LCD Display |
| Phase: |
Three Phase |
| Type: |
On-line |
| Protection: |
Over Load/Current/Voltage, Short Circuit etc |
| Brand: |
Upsen or OEM |
Product Description
Intelligent Double Conversion IGBT DSP Modular UPS Uninterruptible Power Supply For Servers.data system
Model: Modular Online UPS Power Melody Star Series (3ph in/3ph out)
Modular UPS Quick View
1: UPS with 3 Phase 208vac 220Vac or 380Vac 400Vac 415Vac Input and Output
2: UPS with high frequency tech and double conversion design
3: Modular UPS with
4: Strong load adaptability for linear and nonlinear load
5: Modular UPS with pure sine waveform and stable output
Key Features
1.UPS with Modular design and hot swappable.
2. Double DSP controller for individual power module.
3. Strong load adaptability for linear and nonlinear load.
4. Large touch screen LCD with plenty of information.
5. IGBT modules rather than discrete components are applied in the power module.
6. Intelligent module and system protection design.
7. Independent charger for batteries, intelligent battery management system.
8. Totally front access, top and bottom cable connection.
9. Inbuilt power distribution for input and output connection.
10. Incredible low noise system design.
11. Digital paralleling technology, very low circle current between modules.
12. Digital control for the whole parts including rectifier, inverter, charger and discharger.
13. Each individual module is configured with independent controller, avoid single point failure risk.
MS Series 10K-200Kva |
Capacity | 10-200KVA |
Main Input |
Input voltage | 380V/400V/415V(line to line) |
Input frequency | 50/60Hz |
Power factor | > 0.99 |
Input cuurent THD(Total Harmonic Distortion) | < 3% |
Input voltage window | -40%~+25% |
Frequency window | 40-70HZ |
Battery |
Battery voltage | ± 240VDC |
Charger power | 20%*Power |
Charger voltage precision | 1% |
Bypass |
Bypass voltage | 380V/400V/415V, three phase |
Bypass voltage window | -20%-+15%, full load, settable |
Bypass overload capabiltiy | 150%, long time operation |
180%, shut down after 10 minutes |
> 180%, shut down after 200ms |
Output |
Output voltage | 380V/400V/415V, three phase |
Voltage precision | ± 0.5% (balance load), ± 1% (unbalance load) |
Voltage THD(Total Harmonic Distortion) | THD< 1%(linear load), THD< 3%(nonlinear load) |
Power factor | 0.8 |
Phase tolerance | 120° ± 0.5° (balance and unalance load) |
Crest factor | 3: 1 |
Overload capabiltiy | 110%, transfer to bypass after 1hour |
125%, transfer to bypass after 10 minutes |
150%, transfer to bypass after 1 minute |
> 150%, transfer to bypass after 200ms |
System |
System efficiency | Normal mode: 95% |
ECO mode: 99% |
Battery mode efficiency | 95% |
Display | LCD+LED, Touch screen and keyboard |
IP class | IP20 |
Interface (Communication Ports ) | RS232, RS485, Dry contacts, SNMP card, EPO, Generator interface |
Installation/Connection | Top or bottom cable connection |
Operation temperature | 0-40C |
Storage temperature | -25~70C |
Relative humidity | 0-95% (non-comdensing) |
Noise(dB) | < 55dB |
Weight(KG) | 6-module cabinet | 150KG |
10-module cabinet | 180KG |
Module | 10KVA: 20KG |
15KVA: 21KG |
20KVA: 22KG |
Dimension(W*D*H)(mm) | 6-module cabinet | 600*900*1600 |
10-module cabinet | 600*900*2000 |
Module | 400*600*133 (10KVA/15KVA/20KVA) |
Competitive Advantages:
1: Three Years' warranty for Online UPS, and 1% free UPS or 2% free PCB Boards
3: Good after-sales service, we will be full responsible for any faults caused by our side
4: Professional experience in power field more than 10 years
5: Professional technical support before and after sales
6: Timely response, fast delivery time and flexible operations to satisfy any customers' special requests.
7: Free OEM & ODM Service
8: Competitive price, quality and mature products
Shenzhen UPSEN Electronic Co., Ltd. Which is located in south of China, Shenzhen City, close to Pearl of the Orient HK, with beautiful environment and convenient transport.
We are a private high-tech enterprise integrating researching & development, production & operation and technical services as a whole, which is specialized in Electric, Electronic and Energy fields for a long time. Our main products are UPS Power, Inverter Power, Battery Power, Solar&Wind Power. We are dedicated to offer quality power and power solution for Data-center, Telecom, Bank, Hospital, Transportation, Industry, Army, Security, and civil & office area etc. Moreover, we have mastered the core technology of power products through our independent research, we are one of few domestic enterprises which can meet the customers' customized requirements, and provide professional power solutions.
We already past ISO9001 international quality system certification, and established a complete quality system ranging from material source, process, assembling to testing. All our products are with CE Certificate, which exported to more than 30 countries and areas, like Australia, Europe, Africa, North America, South America, the Middle East, central Asia, southeast Asia etc.
We will always offer excellent quality and products to customers. Hope to make Integrity and Double-Win business with you, and to be your professional power supplier and solve your any power problems. We are sure UPSEN can achieve more successes with our efforts and your support.
