Inverter Power Inverter 10kw 250V

Name: Inverter Power Inverter 10kw 250V
Brand: all-electronics-online.com
SKU: 829349075
Availability: InStock
Rating: 4.6 (43 reviews)

Price:	US $ 280-290/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Sofar 10000TL

Product Description

MODEL	Sofar 10000TL	Sofar 15000TLM	Sofar 17000TLM	Sofar 20000TLM
Input(DC)
Maximum output	10400w	15600w	17700w	20800w
Single channel MPPT maximum dc power	6750w(450v-850v)	10500w(500v-850v)	10500w(500v-850v)	12000w(500v-850v)
Number of independent MPPT	2
Maximum input voltage	1000V
Initiating input voltage	350v(+/-1v)
Rated input voltage	600v
MPPT voltage range	250v-960v
Single channel MPPT maximum input current	15A/15A	21A/21A	21A/21A	24A/24A

Single channel MPPT input short circuit current	20A	27A	27A	30A
Output(AC)
Maximum ac power	10000VA	15000VA	17000VA	20000VA
Nominal ac voltage	3/N/PE,220/380 3/N/PE,230/400 3/N/PE,240/415
Nominal ac voltage range	184V-276V
Frequency range	55Hz,+/-5Hz
Maximum output current	15A	22A	25A	29A
Total harmonic component	<3%
performance
Max efficiency	98.2%
Weighted efficiency(Europe/California)	97.6%/97.8%	97.9%/98%	97.9%/98%	98%/98.1%
Self-discharging at night	<1w
Start the power	45w
MPPT efficiency	>99.5%
Protection
Dc reverse protection	yes
Dc switch	standrad
certification	CE,CQC,AS4777,VDE 4105,C10-C11,G59
communication
Standard communication mode	RS485+wifi,GPRS
Job information storage	25years
Conventional data
Ambient temperature range	-25 ~60°c
Protection level	IP65
relative humidity range	0~95% No condensation
Maximum operating altitude	2000m
dB	<45dB
The weight	45kg
Cooling way	Natural cooling
dimension	708.8x492x245.7mm

Packaging & Shipping

Our Services

1. Rich experience in manufacturing and exporting electric equipment.

2. High quality and competitive price.

3. Strict quality control and excellent after-sales service.

4. Manufacturing according to customers requirements is available.

SAFEE ELECTRIC EQUIPMENT Co., Limited, founded in 2013, is set research and development in our country, production, sales in the integration of science and technology communication EQUIPMENT, fittings professional manufacturers, the company headquarters is located in hebei province shijiazhuang qiaoxi, branch is located in hebei xingtai guangzong county industrial area, transportation is work, the environment is superior.

The company covers an area of more than 28000 square meters, The company existing staff 200 people, o quality management personnel more than 20 people, to meet The rapid growth of demand, The company established a long - term development planning and recent plan, enables The system to implement effectively, make The company fast and efficient.

My company 's existing: Steel strand, circuit, iron casting, all kinds of standard parts, safety instruments and other electric products, gradually to export products from domestic transformation.

Specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are sold throughout the country, marketing has entered the export-oriented, products are sold to Asia, Africa, Middle East, Western Europe, eastern Europe and South America market, modern management and perfect after-sales service system, to build China's power industry well-known brands, we will be more hard work, adhering to the principle of quality is the enterprise life, to a higher standard, create value for users, with global cooperation, hand in hand and win-win marketing idea is willing to work with new and old customers at home and abroad hand in hand, altogether will create the glorious future, Sincerely welcome to visit our company, we supply superior quality products and excellent service always.
