IP66 12V 24V DC LED Power Supply 60W Driver

Name: IP66 12V 24V DC LED Power Supply 60W Driver
Brand: all-electronics-online.com
SKU: 821132995
Availability: InStock
Rating: 5 (73 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	HX-12060-A
IP Grade:	IP66
Usage:	LED Power Supply
Output Type:	Dual
Driving Method:	LED Constant Current
Circuit Structure:	Electronic Step-down Transformer
Brand:	Huaxia Lighting

Product Description

·Output constant voltage
·Input range 170-265VAC or 90-130VAC
·Efficiency 85% max.
·Protections:short circuit/ over current/ over load
·Cooling by free air convection
·IP67 design for indoor or outdoor installations .
·Suitable for LED lighting and moving sign applications
·Compliance to worldwide safety regulations for lighting
·Suitable for dry/damp/wet locations

Specification

Model		HX-05060-A	HX-12060-A	HX-24060-A
Output	DC Current	12A	5A	2.5A
	Voltage Accuracy	±0.5V
	Output voltage	5V	12V	24V
	Rated power	60W
Input	Voltage Range	170~265VAC (90-130V can customized)
	Frequency Range	47~63HZ
	Power Factor ( Typ.)	PFC can be customized! Usually PFC 0.6.
	Full Load Efficiency(Typ.)	80%	83%	85%
	AC Current(Typ.)	0.73A/170VAC 0.56A/220VAC 0.47A/265VAC
	Leakage current	0.7mA/220VAC
Protection	Short Circuit	Protection type: Hiccup mode, recovers automatically after fault condition is removed
	Over Current	≤1.4*I out
	Over Load	≤ 120%
Environment	Working TEMP.	-25~+45ºC
	Working Humidity	20~95%RH,non-condensing
	Storage TEM.,Humidity	-40~+80ºC,10~95%RH
	TEMP.coefficient	±0.03%/ºC(0~50ºC)
	Vibration	10~500Hz,5G 12min./1 cycle,period for 72min.each along X,Y,Z axes
Safety&EMC	Safety standards	EN61347-2-13.IP67
	Withstand voltage	I/P-O/P:3.75KVAC;I/P-FG:1.88KVAC O/P-FG:0.5KVAC
	Isolation resistance	I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25ºC/70%RH
	EMC EMISSION	Compliance toEN55015,EN61000-3-2 (>=50%Load)
	EMC IMMUNITY	Compliance to EN61000-4-2,3,4,5,6,8,11,EN61547,Alight industry level
Others	Weight	0.9Kg
	Size	1786653mm(LWH)
	packing	325224176mm/10pcs
Notes	All parameters NOT specially mentioned are measured at 220VAC input , rated load and 25ºCof ambient temperature. 2.Tolerance:includes set us tolerance,line regulation and load regulation .
