Name: IP66 Distribution Box Ht Series 18ways
Brand: all-electronics-online.com
SKU: 780847825
Availability: InStock
Rating: 4.8 (46 reviews)

Price:	US $ 2.5-3.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	HT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Distribution Box:	IP65
OEM And ODM Service:	Different Sizes and Also Make as Per Your Size
Type:	Distribution Metering Box
Structure:	Protection
Brand:	Bsd

Product Description

1,Function
This product applies to terminal of AC 50/60 Hz, rated operating voltage up to 400 V and rated current up to 63A, equipped with various modular electric for function of electric energy distribution, control, (short circuit, overload, earth leakage, over-voltage) protection, signal, measurement of terminal electric appliance.
Equipped with transparent/ non-transparent door
Single row: door open upward 90 degrees.
Rated current: 4 ways 50A, 6-36 ways 63A
Material: insulating, self-extinguishing fire material
Protection level: indirect contact proof 2 protection

2,Main Technical data
1. Equipped with transpartent/non-transparent door
2. Single row: door open upward 90 degrees
3. Rated current: 4 ways 50A, 6~36 ways 63A;
4. Material: Insulating, self-extinguishing fire material
5. Protection level: indirect contact proof 2 protection

Model	Specification	L	W	H
HT	5 ways	120	160	92
	8 ways	200	150	92
	12 ways	255	200	108
	15 ways	310	200	108
	18 ways	370	198	108
	24 ways	355	275	108
HK	5 ways	140	140	105
	8 ways	185	185	105
	12 ways	270	195	105
	18 ways	370	195	105
HA	4ways	210	140	100
	8ways	215	210	100
	12ways	300	260	140
	18ways	410	285	140
	24ways	300	315	140
	54ways	410	655	141
