IP67 252W 1.05A Constant Current Waterproof LED Driver for Streetlight

Name: IP67 252W 1.05A Constant Current Waterproof LED Driver for Streetlight
Brand: all-electronics-online.com
SKU: 730687242
Availability: InStock
Rating: 4.7 (56 reviews)

Price:	Negotiable/Piece
Min Order:	20/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	TLA-252-220C
Usage:	Light
Output Type:	Single
Driving Method:	LED Constant Current
Circuit Structure:	PWM Controlled
In-Out:	Constant Current
Power Supply Voltage:	200-240VAC
Pack Sealing Size:	2529541.8mm
Brand:	Goldpower

Product Description

Specifications :
Model:TLA-252-220C

Input:120-240V

Power:252w

Current:1.05A

Efficiency : 93%

Power factor : >0.98

Description:
1.Wide input:108-305Vac
2.Wide output:152-240Vdc
3.Active PFC THD<20% at 230VAC
4.Protection Short/Over current/Over voltage/Over heated
5.IP level IP65/67,fanless
6.Constant current output
7.Optional dimming 0-10Vdc/PWM,Min 10% flickering-free output
8.Application:Streetlight/Commercial indoor
9.Suitable for outdoor use
10.High efficiency up to 94%
11.6kv surge protection High reliability
12.UL60950-1,IEC60950,UL8750 compliance
13.3 years warranty

Techone was founded in 2003, a leading energy-saving company in the power supply industry. There's an independent industrial park with 80, 000 square meters in Pingshan district, Shenzhen, China. With more than 500 employees and many core intellectual property rights.

We supplies digital power supply units and control solutions, for HID/LED/UV lighting and non-lighting applications. Nowadays, more than one and a half million our product have been working world-wide for general and special applications, such Hydroponics plant growing, street lighting, UV water processing and so on. Our patented devices and technology enable you to save upto 50% energy while delivering the same or more brightness.

We provide a complete line of products for HID/LED/UV system, with mutiple dimming or remote-control, universal AC/DC input and wide-range output power. OEM/ODM is also welcome. Our product has always passed UL certification. Good quality and service will be promised.
