ISO9001 RoHS UL Approved EMS PCB Assembly

Name: ISO9001 RoHS UL Approved EMS PCB Assembly
Brand: all-electronics-online.com
SKU: 810689835
Availability: InStock
Rating: 4.8 (143 reviews)

Price:	US $ 0.67-0.98/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Metal Coating:	Copper
Mode Of Production:	SMT
Layers:	Multilayer
Base Material:	FR-4
Certification:	ISO
Customized:	Customized
Condition:	New

Product Description

SMT Assembly Capabilities
Item	Capabilities
Maximum Layers	20
Maximum Copper Weight	4oz
Board Thickness	0.2mm - 4mm
Smallest Hole Size	0.005"
Via Aspect Ratio (Depth to Diameter)	0.75:1
Smallest Tracing and Spacing	3 mil
Surface Finish	HASL, ENIG, OSP, Gold finger, Electrogilding
Advanced	HDI, Impedance Control, Blind & Buried
Smallest Chip for Assembly	201
Smallest BGA pitch	0.25mm
Maximum Board Size for Assembly	470mm * 550mm

Enjoy your time

Rather than machines, perfect engineering processes are more important.
In this way, the EMS PCB assembly can be managed thoroughly
in right direction with high pass rate.

FAQ

Q : What kind of files you have to send us to get quotation?
A : You have to send us PCB design files (gerbers or .pcb acceptable), Bill of Materials (BOM),
     Quantities to make quote and other technical requirements (.step/.txt/.xls files acceptable)

Q: What payment methods we can support?
A: We accept T/T, L/C, West Union as payment methods. For prototype order, you have to make
    100% payment in advance, but for mass production 70% payment in advance and 30%
     payment before delivery.

Q: What measures we take to avoid counterfeit components?
A: Procurement only from manufacturer or big general agent
Original quality certificate of component can be issued (if necessary)
Inspections of shape, silkscreen and conductivity attributes in incoming quality control
Strong responsibilities and perspectives of long-term relationship

As a service-leading PCB manufacturing and PCB assembly (PCBA) partner, NOD Electronics strives to support international small-medium business with 10+ years engineering experience in Electronic Manufacturing Services (EMS). Our headquarter is located in Guangzhou, China. We have 10, 000 square meters plant, 287 employees and 42 engineers, monthly capabilities of 15, 000 square meters PCB design & fabrication and 80 million spot SMT. We were approved by ISO9001-2008, TS16949, UL, CE, RoHS.

We strive to be your rightest partner in electronic manufacturing serivce with a commitment from creative team members. Do you agree that every electronic product has its soul, bearing the designer's product concept, just like the Apples and Steve Jobs? Electronic product is a bridge between the customer and designer rather than a cold and ruthless object. Although they have no verbal communication, they have soul connection in between.

So, we perform and create a bridge, which turns your concept or design into a product and present in front of the customers by offering reliable manufacturing solutions and engineering support, including New Product Introduction (NPI), Printed Circuit Board (PCB) design, Printed Circuit Board Assembly (PCBA), Casing (plastic & mental) solutions.
