ITG O2 Oxygen Sensor Automotive Sensor 0-25 Vol% O2/A-01

Name: ITG O2 Oxygen Sensor Automotive Sensor 0-25 Vol% O2/A-01
Brand: all-electronics-online.com
SKU: 837456555
Availability: InStock
Rating: 5 (78 reviews)

Price:	US $ 12-120/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	O2/A-01
Output:	TTL/4-20mA/RS485
Transmitter Board:	Integrated/Seperated
Wire:	Two or Three Wire
Detecting Range:	Selectable
After Sale Service:	Yes
Material:	PA 12, PPS, PTFE, Stainless Steel

Product Description

ITG O2 - Industrial Sensor / Type A-01

Galvanic gas sensor designed for use in automotive exhaust gas analysers, released according to PTB 18.10, meets all OIML standards and BAR' O2 requirements.

All characteristics are based on conditions at 25°C, 50% RH and 1013 hPa

Key Feature

Measurement Range	0 to 25 Vol.%
Expected Operating Life	~ 500,000 Vol.% h
Sensor Lifetime	< 3 years @ ambient air
Electrical Connector	3-pin Molex®
Initial Output Signal	8.0 to 14.0 mV @ dry ambient air
Response Time t90	< 5 s
Signal Response to N2	Ua/200 @ 100% N2 in <40s
Drift	10% / year
Operating Temperature	0 to 50 °C
Pressure Range	700 to 1750 hPa
Influence of Humidity	- 0.03 % rel. O2 reading per % RH
Recommended Load Resistor	> 10 kOhm
Temperature Compensation	NTC
Interferences	< 0.1% O2 response to: 15.0% CO2 balanced N2 3,000 ppm C3H8 balanced N2 10.0% CO balanced N2 500 ppm H2S, balanced N2 3,000 ppm NO balanced N2 500 ppm SO2, balanced N2 1,000 ppm Benzene, balanced N2
Weight	approximately 25 g
Material in Contact with Media	PA 12, PPS, PTFE, stainless steel

Storage Condition

Temperature Range	recommended: 5 to 30 °C maximum: -20 to 50 °C
Shelf Life	< 6 months recommended
Ambient Pressure	600 to 1750 hPa

Oxygen Module Parameters

Module type	GM-I2(3)-M/C/S--**/G/P/F/FL
Detected gas	Toxic gas
Detecting principle	Electrochemistry
Sampling	Diffusing pump flange thread
Responding time	30s~40s(of the sensor)
Module accuracy	≤±3%FS(actual concentration, higher accuracy depends on specified sensors)
Module repeatability	≤±2% FS
Module linear error	≤±2% FS
Module zero temperature drift	≤±2% (FS/year)
Module operating temperature	-40~80°C
Module humidity	0-95%RH(non-condensation)
Sensor operating temperature	-20°C~50°C
Sensor humidity	0-90%RH(non-condensation)
Signal output	TTL/4-20mA /RS485 (two or three wire)
Transmitting distance	1000 meters(RS485)
Operating voltage	DC 12-36V
Maximum power	≤0.8W
Size	80*48mm
Explosion proof	Intrinsic safe
Connection cable	RVVP3 x 1.5mm²

Oxygen Module Applications
Petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking, leak detection, safety and environmental control

Company introduction

Advanced Sensors Application Technology Co., Ltd. Was established on 2003. We are passionate about delivering high quality gas sensor products to our customers. Focus on customized manufacturing, we supply widely to many key industries through our diverse and state-of-art facilities. We have a technician team to support in material designs and testing to international standards meeting customers' requirements.

Products are widely used in petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking.
