ITG O2 Oxygen Sensor Industrial Sensor Safety Monitoring 0.5-35 Vol% O2/I-01

Name: ITG O2 Oxygen Sensor Industrial Sensor Safety Monitoring 0.5-35 Vol% O2/I-01
Brand: all-electronics-online.com
SKU: 837974245
Availability: InStock
Rating: 5 (116 reviews)

Price:	US $ 12-120/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	O2/I-01
Output:	TTL/4-20mA/RS485
Transmitter Board:	Integrated/Seperated
Wire:	Two or Three Wire
Detecting Range:	Selectable
After Sale Service:	Yes
Material:	ABS, PVC, PPS, PTFE, Stainless Steel

Product Description

ITG O2 - Industrial Sensor / Type I-01

Sensor contains acid electrolyte to withstand high CO2 concentrations, shows high resistivity to acid gases, a short response time and long lifetime.

All characteristics are based on conditions at 25°C, 50% RH and 1013 hPa

Key Feature

Measurement Range	0.5 to 35 Vol.%
Expected Operating Life	~ 1,200,000 Vol.% h
Sensor Lifetime	< 6 years @ ambient air, depending on application
Electrical Connector	3-pin Molex®
Initial Output Signal	9.0 to 13.0 mV @ dry ambient air
Output Signal Range	5.0 to 20.0 mV @ dry ambient air
Response Time t90	< 5 s
Drift	< 3 % per month, averaged across 12 months
Operating Temperature	0 to 50 °C
Pressure Range	700 to 1250 hPa
Linearity Error	0 to 2 Vol.% O2: ± 0.1 absolute 2.1 to 35 Vol.% O2: ± 0.5 relative
Influence of Humidity	- 0.03 % rel. O2 reading per % RH
Repeatability	± 1 % Vol. O2 @ 100 Vol.% O2 applied for 5 min
Zero Offset Voltage	< 200 μV in 100 % N2 applied for 5 min
Recommended Load Resistor	> 1 MOhm
Temperature Compensation	NTC
Interferences	< 20 ppm O2 response to: < 20.000 ppm O2 response to: 100 Vol.% CO 3,000 ppm NO, balance to N2 100 Vol.% CO2 1,000 ppm H2, balance to N2 100 Vol.% C3H8 500 ppm SO2, balance N2 1,000 ppm Benzene, balance N2 2,000 ppm H2S, balance N2
Weight	approximately 25 g
Material in Contact with Media	ABS, PVC, PPS, PTFE, stainless steel

Storage Condition

Temperature Range	recommended: 5 to 30 °C maximum: -20 to 50 °C
Humidity	up to 100 % RH
Shelf Life	< 6 months recommended
Ambient Pressure	600 to 1250 hPa

Oxygen Module Parameters

Module type	GM-I2(3)-M/C/S--**/G/P/F/FL
Detected gas	Toxic gas
Detecting principle	Electrochemistry
Sampling	Diffusing pump flange thread
Responding time	30s~40s(of the sensor)
Module accuracy	≤±3%FS(actual concentration, higher accuracy depends on specified sensors)
Module repeatability	≤±2% FS
Module linear error	≤±2% FS
Module zero temperature drift	≤±2% (FS/year)
Module operating temperature	-40~80°C
Module humidity	0-95%RH(non-condensation)
Sensor operating temperature	-20°C~50°C
Sensor humidity	0-90%RH(non-condensation)
Signal output	TTL/4-20mA /RS485 (two or three wire)
Transmitting distance	1000 meters(RS485)
Operating voltage	DC 12-36V
Maximum power	≤0.8W
Size	80*48mm
Explosion proof	Intrinsic safe
Connection cable	RVVP3 x 1.5mm²

Oxygen Module Applications
Petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking, leak detection, safety and environmental control

Company introduction

Advanced Sensors Application Technology Co., Ltd. Was established on 2003. We are passionate about delivering high quality gas sensor products to our customers. Focus on customized manufacturing, we supply widely to many key industries through our diverse and state-of-art facilities. We have a technician team to support in material designs and testing to international standards meeting customers' requirements.

Products are widely used in petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking.
