| Prod Model: |
SC/APC-SC/APC |
| Cable Length: |
1m.3m.5m or Customized |
| Operating Temperature: |
-40c~+80c |
| Fiber Mode: |
Single Mode or Multi-Mode |
| Cable Diameter: |
0.9mm,2.0mm,3.0mm |
| Operation Wavelenghth(Nm): |
1310/1550nm |
| Export Markets: |
Global |
| Connector: |
Sc/APC |
| Application: |
FTTH, FTTB, LAN, CATV |
| Type: |
Single-mode Fiber |
| Connection Structure: |
SC |
| Certification: |
CCC |
| Brand: |
Takfly |
| Sheath Material: |
PVC, LSZH |
Product Description
JUMPER SC/APC-SC/APC SM G657A2 Ivory fiber optic Patchcord
1. Details:
Patch cords are ultra reliable components featuring low insertion loss and return loss. They come with your choice of simplex or duplex cable configuration and are made to conform to IEC, Telcordia GR-326-CORE Standard.
2. Features:
Low insertion loss and high return loss
Good exchangeability
Support 10 Gigabit data transmitting rates
MM cables type
FC, LC, SC, MU, ST, MTRJ, E2000, MPO… optional
Polishing: PC, UPC and APC
Meets IEC standard
3. Applications:
Telecommunication networks
Fiber optic communication networks
CATV, LAN, MAN, WAN, Test &Measurement
Military industry
Optical access network
4. Before Sale Service:
We provide professional offer. Provide detailed products test report and related specifications.
We provide professional technology support to meet the requirements of customers.
Within 12 hours of the corresponding customer inquiry, our commissioners will promptly get in touch with the customers.
5. Why contact Takfly Communications Co., Ltd?
The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry.
1. Fast delivery
2. Competitive price
3. Professional product and technical support
4. Prompt answer for any question or inquiry
5. Reliable quality, OEM service available
6. Longtime warranty
7. Value-added service: Except good products, we can provide good services on logistic and other help you may need.
For any question, pls feel free to contact us. Your inquiry is expected! Warmly welcom you to inquiry us for this product
Parameter
| Unit
| Standard & Requirement
|
Insertion loss
| dB
| ≤0.20
|
Changeability
| dB
| ≤ 0.20dB
|
Radius of curvature
| nm
| 10 ≤ r ≥25
|
Curvature eccentricity
| um
| <50
|
Fiber core undercut
| nm
| <50
|
Insertion loss change
| dB
| < 0.1
|
Return loss change
| dB
| < 5
|
Insert & pull out (Max.)
| kg
| 2
|
Insert and pull frequency
| Time
| > 1000
|
Operating temperature
| degree
| -40 ~ +85
|
