Kcd1 White 2p on off Rocker Switch

Kcd1 White 2p on off Rocker Switch
Price: US $ 0.078-0.095/Piece
Min Order: 500/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: KCD1
Usage: Electrical Appliance
Standard: Standard
Lamp: Without Lamp
Color: White
Certification: TUV UL
Condition: New

Product Description


The Main Technical Parameters

ItemMini ON OFF Rocker Switch
MterialPA66 /PC
Rating10A 125VAC/6A 250VAC
Contact Resistance≤50MΩ
Insulation Resistance≥500VDC100mΩ
OperatingTemperature-25C~+85C
Ambient Temperature-10ºC~+85 ºC
Dielectric Strength1500VAC,1 Minute
TypeROCKER SWITCH
Elactric life>10000 Cycles
Electrical Life>50000 Cycles
Terminals & Mid pinsCopper with silver plated
ContactsCopper with compound silver
Terminals & Mid pinsCopper with silver plated

--Production Material---
Base PLASTICNylon 66 T85
Button plasticPC
Copper parts such as terminalCopper
Terminal surface treatmentSilver plating
ContactAg or Composite silver
SpringTungsten steel
Cover plasticPC
