Large Square Extra Soft Silicone Wire Dw10

Name: Large Square Extra Soft Silicone Wire Dw10
Brand: all-electronics-online.com
SKU: 807741535
Availability: InStock
Rating: 4.3 (106 reviews)

Price:	US $ 5.69-10.98/Meter
Min Order:	3000/Meter
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	DW10
Silicone Insulated Soft Wire:	Large Square
Type:	Insulated
Conductor Type:	Stranded
Application:	Underground
Conductor Material:	Copper
Insulation Material:	Silicone Rubber
Certification:	RoHS
Sheath Material:	Silicone Rubber
Brand:	Dewei Wire

Product Description

Large square Extra soft silicone wire DW10
Nominal Voltage: 300V OR 600V
Temperature Range: -60º C to 200º C
Conductor: Tinned, Nickeled, siliver plated, gold plated copper, bare copper
Testing Voltage: 2000V
Insulator: Silicone rubber
O. D. Tolerance: ± 0.10mm
Color: Black-brown-red-orange-yellow-green-blue-violet-gray-white-green/yellow. Ect

AWG	con.of conductor.	Diameter	Thickness of insulator	over diameter	Packing
	NO/mm	mm	mm	mm	mt/coils
7#	2110/0.08	4.24	1.23	6.7	100
6#	2646/0.08	4.75	1.37	7.5	100
5#	3350/0.08	5.34	1.83	9.0	100
4#	4230/0.08	6.05	2.22	10.5	100
3#	3400/0.08	6.73	2.48	11.7	100
2#	4282/0.08	7.57	2.95	13.5	100
