| Prod Model: |
Fiber Optic Adapter |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Products Name: |
Fiber Optic Adapter |
| Brand Name: |
Takfly |
| Model Number: |
PC, Upc, APC |
| Color: |
Customize |
| Cores: |
Hybird Simplex, Duplex, Quad |
| Exchangeability: |
<0.2dB |
| Insertion Loss: |
<0.2dB |
| Ing Temperature: |
-40c ~ +85c |
| Export Markets: |
Global |
| Transmission Medium: |
Single-Mode |
| Structure: |
SC |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
PC(',UPC) |
Product Description
LC,FC,SC,ST SM MM Hybrid FTTH Adapter/Fiber Optic Adapter
Product Description
Takfly specialize in: Fiber Optic Patch Cord, Patch Cord, optical fiber patch cord, optical patch cord, Fiber Patch Cord, Fiber Patch Cable, Fiber Optic jumper, Optical Fiber jumper, sc patch cord, singlemode patch cord.
Fiber optic adapters is also called mating sleeves, which are used to connect optical connectors of same type, such as FC, SC and ST. Optical adapters are widely uses in light distribution frame(ODF), the optical fiber communications equipment, the measuring appliance and so on.
The optical adapter connects fiber transmission by its placket tube. We offer various shapes of high-performance adapters to ensure maximum connectivity between the fiber jumper. In order to fix a varity of board level, our company designed various sophisticated fixed flange.
LC,FC,SC,ST SM MM Hybrid FTTH Adapter/Fiber Optic Adapter
Packaging & Delivery
Packaging Detail: Each one package in a plastic box, and then package it with a specification in a carton about 60mm*60mm*80mm volume.
LC,FC,SC,ST SM MM Hybrid FTTH Adapter/Fiber Optic Adapter
Delivery Detail: Delivered Within One Week after Order Confirmed
LC,FC,SC,ST SM MM Hybrid FTTH Adapter/Fiber Optic Adapter
Specifications
1. High reliability
2. Good exchangeability
3. Excellent directivity
4.8 years of experiences
LC,FC,SC,ST SM MM Hybrid FTTH Adapter/Fiber Optic Adapter
Order Information
1. Type: SC, LC, ST, FC, MU, E2000, Hybrid
2. Endface type: PC UPC APC.
3. Singlemode or Multimode.
4. Simplex, Dumplex or Quad.
Parameter
| Insertion loss(dB) | ≤ 0.20 |
| Duplication (dB) | ≤ 0.10 |
| Interchangeability (dB) | ≤ 0.20 |
| Sleeve material | Ceramics |
| Operating temperature (°C) | -25 ~ +70 | -40 ~ +80 | -25 ~ +70 |
| Storage temperature (°C) | -40 ~ +85 |
