LC-FC Singlemode Duplex Patch Cord/Patchcord for FTTH

Prod Model:	PCLUFU2SM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insert Loss:	< 0.20dB
Return Loss:	> 50dB
Diameter:	2.0mm,3.0mm
Application:	Communication
Type:	Single-mode Fiber
Connection Structure:	FC-LC
Certification:	ISO9001
Brand:	Datolink

Product Description

LC stands for Lucent Connector. The LC is a small form-factor Fiber optic connector.
The LC Connector uses a 1.25 mm ferrule, half the size of the ST. Otherwise; It is a standard ceramic Ferrule connector. The LC has good performance and is highly favored for single mode.

FC stands for Fixed Connection. It is fixed by way of threaded barrel housing. FC connectors are typical in test environments and for single mode applications. FC connectors were designed for use in high-vibration environments. The FC Connector is the most popular connector used today. It can be seen in every area of the communications environment, from a telecom's distribution room to a LAN closet, the FC has set the standard for optical Fiber connectors. FCS are being replaced by SC and LC connectors.

Features:

Low insertion loss(≤ 0.20dB)and high return loss(≥ 55 dB)
Free-floating ceramic ferrule
UL-rated plastic housing and boot
Boots in a variety of colors
High precision alignment connector

Applications:

Local Area Networks (LANs) and Wide Area Networks (WANs)
Fiber Optic CATV, FTTH, FTTB, FTTP etc
Fiber Optic telecommunication systems
Transmission Mode (ATM)
Fiber Optic Backbone
Military Instrumentation

Specifications
	Single mode	Multimode
Insert Loss	≤0.20dB	≤0.25dB
Return Loss	≥50 dB (PC)
	≥55 dB (UPC)
	≥65 dB (APC)
Durability	<0.20 dB typical change, 1000 mating
Operating Temperature	From -40 to + 80°C	From -40 to + 80°C
Ferrule Hole Sizes	125.0+1/-0μm, Concentricity: ≤1.0μm	125μm, Concentricity: 1≤3μm
	125.5+1/-0μm, Concentricity: ≤1.0μm	127μm, Concentricity: 1≤3μm
	126.0+1/-0μm, Concentricity: ≤1.0μm	128μm, Concentricity: 1≤3μm
