LC-St Sm Duplex Patchcords/Patch Cord

Name: LC-St Sm Duplex Patchcords/Patch Cord
Brand: all-electronics-online.com
SKU: 709329965
Availability: InStock
Rating: 4.3 (66 reviews)

Price:	US $ 2/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	PCLUTU2SM
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Insert Loss:	< 0.20dB
Return Loss:	> 50dB
Diameter:	2.0mm,3.0mm
Application:	Communication
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	LC-St

Product Description

LC stands for Lucent Connector. The LC is a small form-factor Fiber optic connector.
The LC Connector uses a 1.25 mm ferrule, half the size of the ST. Otherwise; It is a standard ceramic Ferrule connector. The LC has good performance and is highly favored for single mode.

ST stands for Straight Tip - a quick release bayonet style Connector developed by AT&T. STs were predominant in the late 80s and early 90s.

Features:

Low insertion loss(≤ 0.20dB)and high return loss(≥ 55 dB)
Free-floating ceramic ferrule
UL-rated plastic housing and boot
Boots in a variety of colors
High precision alignment connector

Applications:

Local Area Networks (LANs) and Wide Area Networks (WANs)
Fiber Optic CATV, FTTH, FTTB, FTTP etc
Fiber Optic telecommunication systems
Transmission Mode (ATM)
Fiber Optic Backbone
Military Instrumentation

MECHANICAL, ENVIRONMENTAL & MATERIAL DATA
Range of Mode	Single or Multimode
Cable Type	Simplex or Duplex Zipcord
Connector Style	SC, FC, ST, LC, MTRJ, E2000
Polish or Ferrule Interface Type	PC, UPC, APC
Cable Diameter	0.9mm, 1.6mm, 2.0mm, 3.0mm
Lengths	Standard & Custom Lengths
Strength Member	Aramid Yarn
Outer Jacket	PVC or LSZH
Cable Assembly Length (<15 meter Tolerance)	-0/+100mm
Cable Assembly Length (>15 meter Tolerance)	-0/+10%
Jacket Color (Multimode: OM1 & OM2)	Orange
Jacket Color (Multimode: OM3 & OM4)	Aqua
Jacket Color (Single Mode: G652D & Gb57A)	Yellow
Durability	500 cycles(0.2 dB max increase), 1000 mate/demate cycles
Operating Temp.	-20°C to +70°C /+85°C(armoured)
Storage Temp.	-40 °C to +85°C
Ferrule Concentricity	< 1μm, Other Ferrule Concentricity < 1μm
Humidity (FOTP-5)	90-95% at 40°C
Strength of Coupling Mechanism (FOTP-185)	33 N at 0° for 5 sec
Cable Retention (FOTP-6)	50 N at 0° for 5 sec.
Twist (FOTP-36)	15 N at 0° 5 turns, 10 cycles
Flex (FOTP-1)	0.5 Kg at 25 cm, +90° to -90°, 100 cycles

Specifications:

Item	Unit	FC,SC,ST/PC	FC,SC,ST/UPC	FC,SC,ST/APC
Insertion Loss	dB	≤0.20	≤0.20	≤0.30
Repeatability	dB	≤0.10
Exchangeability	dB	≤0.20
Return Loss	dB	≥45(SM)	≥50(SM)	≥60(SM)
Fiber Type		Corning SMF-28TM, 9/125um (SM), 50/125um or 62.5/125um(MM)
Operating Temperature	°C	-40~+80
Storage Temperature	°C	-40~+85
Durability	time	>1000 times
Industry Standard	Telcordia GR-326-CORE

Any question,pls leave me an inquiry or contact me directly.
