LCD Display Controller Board Made in China

Prod Model:	PCBA
Prototype Run:	Yes
Mass Production:	Yes, After Samples Confirmed Ok
Copper Thickness:	0.5-2oz
Board Thickness:	1.6mm
Place Of Origin:	Guangdong, China (Mainland)
Surface Finishing:	HASL,HASL Lead Free,OSP,Immersi
Layout:	1-22 Layer
Metal Coating:	Copper
Mode Of Production:	SMT
Layers:	Double-Layer
Base Material:	FR-4
Certification:	SGS
Customized:	Customized
Condition:	New

Product Description

           LCD display controller Board made in China

Shenzhen Rigao Electronics is an OEM manufacturer of PCB and PCBA, We also can design
PCB and PCBA for your as your request.

 Single-side,double-sided and multilayer PCB and PCB Assembly manufacturer/OEM
Flexible flat cable,  FPC flat cable connectors
- Contract Manufacturing
- Mixed-technology (High speed SMT & Through hole assembly)
- PCB Design & Assembly and copy service
- Prototyping
- Components purchasing
- Metal box,Coil,Cable and Wire Assemblies
- Plastics and Molds
- Fast turn around


General Specifications  Capability

Material Requirements:

Size	Max.Finshed Size	20.9"x24.4"(530mm x 620mm )
Board Thickness	Standard	0.004"to0.16 " ±10% ( 0.1mmto4.0mm±10% )
	Min.	Single/ Double-sided:0.008"±0.004"(0.2mm ±0.1mm)
		4-layer:0.01"±0.008"(0.4mm ±0.1mm)
		8-layer :0.01"±0.008"(0.4mm ±0.1mm)
	Bow and twist	< 7/1000
Copper  Weight	Outer Cu weight	0.5oz ~ 3.0oz
	Inner Cu wight	0.5oz ~ 3.0oz
Laminate Materials	FR-4,FR-1,,FR-2,CEM-1,CEM-3



Process Requirements:


Solder Mask	Color	green,light green,white,black,dark brown,yellow,red,blue
	Min. solder mask clearance	0.003"(0.07mm)
	Thickness	0.0005"-0.0007"(0.012mm-0.017mm)
Silkscreen	Color	White,black,yellow,red,blue,green
	Min. Size	0.006"(0.15mm)
Surface Finish	HASL,HASL pb free,immersion gold,immersion silver,immersion tin,O.S.P (Entek),S/G plating,ENEPIG,G/F plating,carbon



Quality Control:


Electrical testing	Flying Probe Tester	Y
Controlled Impedance	Tolerance	±10%
	Impedance tester	Tektronix TDS8200
Routing	End Mills Test	± 0.006"(0.15mm)
	CNC Tolerance	±0.004"(0.1mm)
	V-Cut Depth V-cut	FR-4(1/3+-0.1mm);FR-1,FR-2,CEM-1,CEM-3(1/2+-0.1mm)
	V-cut angle V-CUT	15°,18°,30°
	V-CUT	line,hole,V-shape



Certificates


UL Cert.	Y
ISO Cert.	ISO9001 :2008
TS16949	Y
ISO14000	Y



Manufacturing Capability for PCB Board

1). Material type: CEM-3,FR-4,FR-4-TG170/TG180,Halogen Free,Rogers,Arlon,Taconic,Isola,PTFE, Bergquist
2). Surface Treatment: HASL,HASL lead-free,HAL,Flash gold,immersion gold,OSP,Gold Finger Palting,Selective thick gold plating, immersion silver,immersion tin, Carbon ink,peelable mask
3). Solder mask colour: Green/MATT Green/Blue/Yello/White/Black/Red
4). Board Size: 650mm*1000mm
5). Board Layer: 1L-26L
6). Board thickness: 0.2mm to 6.0mm
7). Finished Copper thickness: 0.5 OZ to 6 OZ
8). Min. drilled hole size: 3mil (0.075mm)
9). Min. Line width/Line spacing: 3mil/3mil
10). Copper thickness in hole: >20um
11). Board thickness tolerance: ±10%
12). Outline tolerance: Routing:±0.1mm,Punching:±0.1mm
13). Hole tolerance: PTH: ±0.076mm , NPTH: ±0.05mm
14). impedance control tolerance: ±10%
15). Warp and Twist: <0.75%
16). Tested by:Flying-Probe Tester, Fixture tester , Visual Inspection
17). Special requirements: Buried and blind vias, impedance control, thick Cu PCB,selectivity plating gold 30 microinch
18). Profiling: Punching, Routing, V-CUT, Beveling
19). Certificate: UL,ISO 9001,ISO14001,ROHS
20). We have a sound quality management system,Ensure the quality of all products

PCBA show:


Features:
Dimension: 30mm*28mm
Base Material: 0.1mm Cu/25um ADH/25um PI+25um ADH/35um Cu/
20um ADH/ 35um Cu/ 2525um PI+25um ADH/
25um ADH/ 0.1mm Au
Thickness: 1.6mm
Line Width/Space: 0.15mm/0.15mm
Surface Treatment: ENIG: Au: 0.03-0.09um, Ni: 2-6um
Minimum via diameter: 0.2mm
The smallest hole: 0.35mm
Outline Tolerance: +/-0.2mm
